Celshading with shadow texture

A simple and highly customizable cel shader with a diferent texture on the shadows!

maybe in the future I’ll make something similar to the lighting as well, but i dont see a cool use for it

I hope you use it in your next project :] :p

Shader code
shader_type spatial;
render_mode blend_mix, depth_draw_opaque, cull_back, diffuse_lambert, specular_schlick_ggx;

uniform sampler2D albedo_texture  : source_color;
uniform sampler2D shadow_texture  : source_color;
uniform float shadow_threshold    : hint_range(0.0, 1.0) = 0.30;
uniform float specular_threshold  : hint_range(0.0, 1.0) = 0.70;
uniform float specular_strenght   : hint_range(0.0, 0.5) = 0.50;
uniform float highlight_threshold : hint_range(0.0, 1.0) = 1.00;
uniform bool only_colored_specular = true;


void fragment() {
	// Normal texture
	vec4 uv_texture = texture(albedo_texture, UV);
	ALBEDO = vec3(uv_texture.xyz);
}

void light() {
	// basic light
	float base_light = clamp(dot(NORMAL, LIGHT), 0.0, 1.0) * ATTENUATION;

	// all threshholds
	bool shadow = base_light >= shadow_threshold;
	bool specular = base_light >= specular_threshold;
	bool highlight = base_light >= highlight_threshold;

	// shadow output
	DIFFUSE_LIGHT = vec3(shadow ? 1.0 : 0.0);

	// specular highlights
	vec3 color = LIGHT_COLOR;

	// only colored check
	if (only_colored_specular == true) {
		float color_avarage = (color.x + color.y + color.z) / 3.0; // greyscale
		bool is_colored = color_avarage <= 2.0; // checks if it's colored based on greyscale
		color *= vec3(is_colored ? 1.0 : 0.0); // to vec3 (color)
	}

	// get colored specular
	vec3 specular_vec_color = color * vec3(specular ? 1.0 : 0.0) * vec3(specular_strenght);
	// specular + highlights
	vec3 specular_out = specular_vec_color + vec3(highlight ? 1.0 : 0.0);
	// specular + shadow texture only on shadow
	specular_out += texture(shadow_texture, UV).xyz * vec3(shadow ? 0.0 : 1.0);

	// specular and highlights output
	SPECULAR_LIGHT = specular_out;
}
The shader code and all code snippets in this post are under CC0 license and can be used freely without the author's permission. Images and videos, and assets depicted in those, do not fall under this license. For more info, see our License terms.
