Realistic Photography Camera

This is a shader + script for Godot 4.6+ that attempts to emulate most of the settings in a DSLR/film camera.  A camera like this is really fun to run around with in almost any 3D game!

It is worth mentioning that this is not 100% realistic, as Godot lets us have more control than a normal camera would have. Also I had to do a lot of research for this shader, so im sure I got some things wrong!

Features

● F-Stop, controlling depth of feild, exposure, and noise.

● Shutter speed, controlling motion blur, exposure, and noise. Supports long shutter speeds by stacking frames on top of each other to produce proper motion blur and reduced noise.

● ISO affecting exposure and read noise.

● Exposure calculation based realistically off of f-stop, shutter speed, iso, and base EV

● Blobby, film-like noise that is applied realistically based on fstop, shutter speed, and ISO settings.

● Supports camera zoom and setting focal distance

● Saves pictures to an output directory, so players can look back on them, share them, or you can have them loaded later in your game

● All image processing and saving is done on a seperate thread to prevent any freezing when taking pictures

● Customizable drawn UI to display center, rule of thirds, and frame guides – automatically adjusts with settings.

NOTE: Currently only Manual mode is supported, but I plan to add auto and semi-auto in the future!

How To Use

Check out the example godot project if you have any issues -> https://github.com/TuniTem/shaders-demo

1. Create a new scene, and make a hierarchy that looks like the one below:

Texture Rect [Anchors Preset = Full Rect] [create realsitic_camera.gd script on this] [Add a viewport texture and set it to the new SubViewport after it is created]

    ⤷ SubViewport

         ⤷ Camera3D [create camera_accumulation.gd script on this]

         ⤷ WorldEnviroment

         ⤷ ColorRect [Anchors Preset = Full Rect] [Create shader material w/ realistic_camera_effects.gdshader]

2. Copy/paste the code:

realsitic_camera.gd:

@tool
extends TextureRect
class_name RealisticCamera

enum Mode {
	MANUAL,
	#SEMI_AUTOMATIC,
	#AUTO
}

enum Aspect {
	SQUARE,
	STANDARD,
	HIGH
}

const MAX_RENDER_DISTANCE = 4000.0
const APERATURE_DIAMETER = 450.0
const AUTO_FOCUS_SPEED = 1.0
const ASSUMED_FPS = 60.0
const MAX_MOTION_BLUR_AMOUNT = 0.3365

const ASPECT_TO_RATIO : Dictionary[Aspect, float] = {
	Aspect.SQUARE : 1.0,
	Aspect.STANDARD : 4.0 / 3.0,
	Aspect.HIGH : 16.0 / 9.0
}

## The location that photos will be saved, has to be in the user:// directory
## if you want someting outside the user dir you need to rewrite the verify_dir() function
@export var photo_save_location : String = "user://"

## The name of the created file, you can use the tags
## [year], [month], [day], [hour], [minute], [second] to insert a timestamp
@export var photo_save_name : String = "Photo [month]-[day]-[year]T[hour]-[minute]-[second]"
@export var viewport_size : Vector2 = Vector2(1920, 1080):
	set(val):
		viewport_size = val
		if not Engine.is_editor_hint(): await RenderingServer.frame_post_draw
		viewport.size = viewport_size

## How far into the frame the photo should be taken, enable [param draw_aspect_corners] to see the effect clearly
@export_range(0.0, 0.95, 0.001) var aspect_inset_amount : float

@export_category("Camera Settings")
## The focal point, aka where depth of feild is focused on
@export_range(0.01, MAX_RENDER_DISTANCE, 0.001, "exp", "suffix:m") var focal_distance : float = 1.0:
	set(val):
		focal_distance = val
		if not Engine.is_editor_hint(): await RenderingServer.frame_post_draw
		camera_attributes.frustum_focus_distance = focal_distance

## The angle of view (aka FOV) of the camera
@export_range(1.0, 179.0, 0.001, "exp", "degrees") var zoom : float = 30.0:
	set(val):
		zoom = val
		if not Engine.is_editor_hint(): await RenderingServer.frame_post_draw
		camera.fov = zoom

## A smaller Fstop means a shallower depth of feild and a brighter image
@export_range(1.0, 32.0, 0.001, "exp") var fstop : float = 4.0:
	set(val):
		fstop = val
		if not Engine.is_editor_hint(): await RenderingServer.frame_post_draw
		shader.set_shader_parameter("fstop", fstop)
		camera_attributes.frustum_focal_length = APERATURE_DIAMETER / fstop

## A smaller shutter speed means a darker image and less motion blur
@export_range(1.0 / 60.0, 4.0, 0.00001, "exp", "suffix:s") var shutter_speed : float = 1.0 / 60.0:
	set(val):
		shutter_speed = val
		if not Engine.is_editor_hint(): await RenderingServer.frame_post_draw
		shader.set_shader_parameter("shutter_speed", shutter_speed)

## A smaller ISO means a darker image, which tends to lead to less grain
@export_range(100.0, 25600.0, 10.0, "exp") var iso : float = 400.0:
	set(val):
		iso = val
		if not Engine.is_editor_hint(): await RenderingServer.frame_post_draw
		shader.set_shader_parameter("iso", iso)

## The mode of the camera, currently only manual is supported as I was having issues with the others
@export var mode : Mode = Mode.MANUAL:
	set(val):
		mode = val
		if not Engine.is_editor_hint(): await RenderingServer.frame_post_draw
		match mode:
			#Mode.AUTO:
				#iso = 400
				#shutter_speed = 1.0 / 30.0
				#fstop = 1.5
				#camera_attributes.auto_exposure_enabled = true
				#auto_raycast.enabled = true
			#
			#Mode.SEMI_AUTOMATIC:
				#iso = 400
				#camera_attributes.auto_exposure_enabled = true
				#auto_raycast.enabled = false

			Mode.MANUAL:
				camera_attributes.auto_exposure_enabled = false

## The aspect ratio of the final shot, enable [param draw_aspect_corners] to see the effect clearly
@export var aspect_ratio : Aspect = Aspect.STANDARD

@export_category("Drawing")

## Draws the corners of the taken frame
@export var draw_aspect_corners : bool = true
@export var aspect_corners_color : Color = Color.WHITE
@export_range(0.0, 1.0, 0.001) var aspect_corners_length : float = 0.05

## Draws a rule of third guide
@export var draw_rule_of_thirds : bool = false
@export var rule_of_thirds_color : Color = Color.WHITE
@export_range(0.0, 1.0, 0.001) var rule_of_thirds_length : float = 0.05

## Draws a crosshair at the center of the camera
@export var draw_crosshair : bool = false
@export var crosshair_color : Color = Color.WHITE
@export_range(0.0, 128.0, 0.001) var crosshair_length : float = 20.0

## The line width of all draw calls
@export_range(-1.0, 16.0, 1.0) var line_width : int = 2

@export_category("Nodes")
## A node who's transform will be copied to the camera's transform.
## Basically think about it as the object representing the realistic camera.
@export var camera_transform_track : Node3D
## The camera in the subviewport
@export var camera : Camera3D
## The default camera of the game, enabled and disabled as the realistic camera is toggled
@export var default_camera : Camera3D
## The camera atributes thats used on the world enviroment node, doesn't need to be modified
@export var camera_attributes : CameraAttributesPhysical
## The screenspace effects shader placed on a color rect in the subviewport
@export var shader : ShaderMaterial
## The subviewport where the cameras output will be rendered
@export var viewport : SubViewport
## The world enviroment in the viewport
@export var environment : WorldEnvironment

## if a picture is currently being taken
var capturing : bool = false
## if the ui is shown
var active : bool = false

# multithreading
const THREAD_TIMEOUT_TIME = 90.0

var _thread : Thread = Thread.new()
var _thread_timeout : float = 0.0
var _quit_thread_flag : int

func _ready() -> void:
	# Set the max render distance
	camera_attributes.frustum_far = MAX_RENDER_DISTANCE
	camera.far = MAX_RENDER_DISTANCE

	# set the subviewport's options
	viewport.use_taa = true
	viewport.use_debanding = true

	# make sure the output directory exists if the game is open
	if not Engine.is_editor_hint(): _verify_dir(photo_save_location)

	# disable the camera by default
	enable_visual(false)

func _process(delta: float) -> void:
	# copy the remote transform's global transform to the subviewport camera
	if camera_transform_track: camera.global_transform = camera_transform_track.global_transform
	queue_redraw()

func _draw() -> void:
	# some draw call magic
	if draw_crosshair:
		for line : Vector2 in [Vector2.UP, Vector2.DOWN, Vector2.LEFT, Vector2.RIGHT]:
			draw_line(size / 2.0, size / 2.0 + line * crosshair_length, crosshair_color, line_width)

	if draw_aspect_corners or draw_rule_of_thirds:
		var aspect : float = ASPECT_TO_RATIO[aspect_ratio]
		var height : int = roundi(size.y * (1.0 - aspect_inset_amount))
		var width : int = roundi(height * aspect)
		var image_dimentions : Vector2 = Vector2(width, height)
		var center : Vector2 = size * 0.5
		var length : float = lerpf(0.0, width, aspect_corners_length)

		if draw_aspect_corners:
			for line : Vector2 in [Vector2(0.5, 0.5), Vector2(-0.5, 0.5), Vector2(-0.5, -0.5), Vector2(0.5, -0.5)]:
				var origin : Vector2 = center + image_dimentions * line
				draw_line(origin, origin + Vector2(-line.x, 0.0) * length, aspect_corners_color, line_width)
				draw_line(origin, origin + Vector2(0.0, -line.y) * length, aspect_corners_color, line_width)

		if draw_rule_of_thirds:
			length = lerpf(0.0, width, rule_of_thirds_length)
			var vertical_length : float = clamp(length, 0.0, image_dimentions.y / 3.0)
			length = clamp(length, 0.0, image_dimentions.x / 3.0)
			var sixth : float = 1.0 / 6.0
			for line : Vector2 in [Vector2(sixth, sixth), Vector2(-sixth, sixth), Vector2(-sixth, -sixth), Vector2(sixth, -sixth)]:
				var origin : Vector2 = center + image_dimentions * line
				draw_line(origin - Vector2(line.x, 0.0).normalized() * length, origin + Vector2(line.x, 0.0).normalized() * length, rule_of_thirds_color, line_width)
				draw_line(origin - Vector2(0.0, line.y).normalized() * vertical_length, origin + Vector2(0.0, line.y).normalized() * vertical_length, rule_of_thirds_color, line_width)

## function used to queue threads for image processing and saving, so the main game doesnt freeze
func _queue_thread(callable : Callable, args : Array = [], custom_timeout : float = -1.0, priority : Thread.Priority = Thread.Priority.PRIORITY_NORMAL) -> Variant:
	while _thread.is_alive():
		await get_tree().process_frame

	_thread.start(callable.bindv(args), priority)
	_thread_timeout = THREAD_TIMEOUT_TIME if custom_timeout == -1.0 else custom_timeout
	while _thread.is_alive() and _thread_timeout > 0.0:
		_thread_timeout -= get_process_delta_time()
		await get_tree().process_frame

	if _thread_timeout <= 0.0:
		printerr("Thread timed out: " + str(callable))
		_quit_thread_flag = callable.get_object().get_instance_id()
		return null
	else:
		return _thread.wait_to_finish()

## make sure the inputed directory exists, only check in user://
func _verify_dir(path : String):
	path = path.replace("user://", "")
	var dir = DirAccess.open("user://")
	if not dir.dir_exists(path):
		var files : Array = path.split("/")
		var curr_dir = files.pop_front()
		for file in files:
			dir.make_dir(curr_dir)
			curr_dir = curr_dir + "/" + file

## enable/disable the camera overlay
func enable_visual(on : bool):
	camera.current = on
	default_camera.current = !on
	visible = on
	active = on
	if on:
		environment.camera_attributes = camera_attributes
	else:
		environment.camera_attributes = null

## toggle the camera overlay
func toggle_visual():
	enable_visual(!active)

## capture a photo, and return an image object. If [param ignore_capture_check] is true,
## multiple pictures can be taken at once before previous ones have processed
func capture(ignore_capture_check : bool = false):
	if not capturing or ignore_capture_check:
		capturing = true
		var aspect : float = ASPECT_TO_RATIO[aspect_ratio]

		var height : int = roundi(viewport.size.y * (1.0 - aspect_inset_amount))
		var width : int = roundi(height * aspect)

		var output : Image
		var base_format : Image.Format
		var operation_format : Image.Format = Image.Format.FORMAT_RGBF
		var frame : int = roundi(ASSUMED_FPS * shutter_speed)
		var frames : Array[Image]

		if frame > 1:
			shader.set_shader_parameter("motion_blur_enabled", true)
			camera.strength = MAX_MOTION_BLUR_AMOUNT

		for i in range(frame):
			await RenderingServer.frame_post_draw
			var img : Image = viewport.get_texture().get_image()
			if i == 0: base_format = img.get_format()
			frames.append(img)

		shader.set_shader_parameter("motion_blur_enabled", false)

		if frame > 0:
			output = await _queue_thread(_combine_frames, [frames, width, height, operation_format, viewport.size], 120.0, Thread.PRIORITY_HIGH)
			print("Combined image layers...")
			output.convert(base_format)
			capturing = false
			return output

## captures an image fromthe camera and saves it to a specifiecd path (or the default path if none is given)
## If [param ignore_capture_check] is true, multiple pictures can be taken at once before previous ones have processed
func capture_and_save(ignore_capture_check : bool = false, path : String = ""):
	if not capturing or ignore_capture_check:
		var image : Image = await capture(ignore_capture_check)
		capturing = true

		var time = Time.get_time_dict_from_system()
		var date = Time.get_date_dict_from_system()
		var file_name : String = photo_save_name
		for replace : Array in [["[month]", date.month], ["[day]", date.day], ["[year]", date.year], ["[hour]", time.hour], ["[minute]", time.minute], ["[second]", time.second]]:
			file_name = file_name.replace(replace[0], str(replace[1]))

		file_name += ".png"

		await _queue_thread(_save_photo.bindv([image, (photo_save_location if path == "" else path) + "/" + file_name]))
		print("Photo saved to ", ProjectSettings.globalize_path((photo_save_location if path == "" else path) + "/" + file_name))
		capturing = false

## Save the photo to the specified path, in a sperate func to be multithreaded
func _save_photo(image : Image, path : String):
	image.save_png(path)

## if the image has a large shutter speed, this layers multiple fromes on top of eachother to emulate that effect
func _combine_frames(frames : Array[Image], width : int, height : int, format : Image.Format, viewport_size : Vector2i) -> Image:
	var output = Image.create_empty(width, height, false, format)
	output.fill(Color.BLACK)
	var frame : float = float(frames.size())
	for img : Image in frames:
		img.convert(format)
		var cropped : Image = Image.create_empty(width, height, false, format)
		cropped.blit_rect(img, Rect2i((Vector2(viewport_size) - Vector2(width, height)) * 0.5, Vector2(width, height)), Vector2i.ZERO)

		# TODO have image layers accumulate on the gpu in some way instead of iterating over pixels, multithreading it is a meh workaround
		# could use a subviewport on rendermode no clear and then stack transparent frames with that maybe? Or a accumulation shader
		# if you figure this out, open an issue/pr on the demo github or contact me: tunitem (discord)
		for x in range(width):
			if _quit_thread_flag == get_instance_id(): return
			for y in range(height):
				output.set_pixel(x, y, output.get_pixel(x, y) + cropped.get_pixel(x,y) / frame)

	return output

camera_accumulation.gd:

extends Camera3D

# Motion blur controller modified from https://godotshaders.com/shader/3d-camera-smooth-motion-blur/

@export_range(0.0, 1.0) var strength: float = 0.3365
@export_range(4, 32) var blur_samples: int = 16
@export_range(0.0, 1.0) var smoothing: float = 0.6056
@export var shader : ShaderMaterial

var prev_pos := Vector3.ZERO
var prev_basis := Basis()
var current_blur := Vector2.ZERO

func _ready() -> void:
	shader.set_shader_parameter("samples", blur_samples)
	prev_pos = global_position
	prev_basis = global_transform.basis

func _physics_process(delta) -> void:
	if delta <= 0: return

	var linear_vel = (global_position - prev_pos) / delta

	var delta_basis = prev_basis.inverse() * global_transform.basis
	var delta_quat = Quaternion(delta_basis)

	var angular_vel := Vector3.ZERO
	if abs(delta_quat.w) < 1.0:
		var half_angle = acos(clamp(delta_quat.w, -1.0, 1.0))
		if half_angle > 0.0001:
			var sin_half = sin(half_angle)
			angular_vel = Vector3(delta_quat.x, delta_quat.y, delta_quat.z) / sin_half * (2.0 * half_angle / delta) * 5.0

	var local_vel = global_transform.basis.inverse() * linear_vel

	var raw_blur = Vector2(
		-angular_vel.y - local_vel.x,
		angular_vel.x + local_vel.y
	) * strength * delta

	var t = 1.0 - pow(smoothing, delta * 60.0)
	current_blur = current_blur.lerp(raw_blur, t)

	shader.set_shader_parameter("blur_direction", current_blur)
	prev_pos = global_position
	prev_basis = global_transform.basis

realistic_camera_effects.gdshader is found in the shader code at the bottom of the page.

3. Place the newly created scene wherever you plan on using it, I reccomend having it wherever you have your main camera (so usually in player.tscn) or in a UI node.

4. Assign all the values

realsitic_camera.gd (on the root TextureRect):

● Camera Transform Track: A 3D node that the realistic camera will be locked to.

● Camera: The camera in your created subviewport

● Default Camera: The general camera that is used when not inside the realistic camera menu, not required, but the game will be rendered twice if not set.

● Camera Attributes: Used for depth of feild, just create a new camera attributes and leave it in there

● Shader: The ShaderMaterial on the newly created ColorRect

● Viewport: The newly created SubViewport

● Environment: The newly created WorldEnvironment

● Concider the settings for various overlays in the “Drawing” section

camera_accumulation.gd (on the new Camera3D):

● Shader: The ShaderMaterial on the newly created ColorRect

realistic_camera_effects.gdshader (The ShaderMaterial on the newly created ColorRect)

● feel free to mess around with the different color’s intensities/scales in the “Noise Settings” tab of the shader uniforms to get a flavor of noise that works well for your game.

● You can change the Base EV depending on how dark/bright your game is.

5. Create an implementation of the settings for your game.

This should be pretty easy! I tried to make it as straightforward as possible. Here it the minimum viable implementation of the camera. In the demo project I have this little snipbit in the character controller:

#Assuming the RealisticCamera is a child of the player
@onready var realistic_camera: RealisticCamera = %RealisticCamera

func _input(event: InputEvent) -> void:
	if event.is_action_pressed("camera"):
		realistic_camera.toggle_visual()

	if event.is_action_pressed("take_picture") and realistic_camera.active:
		realistic_camera.capture_and_save(true)

Here is a list of all of the variables/functions you may or may not want to expose in your UI:

– func toggle_visual(), toggles whether the camera UI is shown or not

– func enable_visual(), sets the camera UI to on or off

– func capture_and_save(), takes a picture with the current camera settings and saves it to either the path at photo_save_location or a specified path fed into the function. Call with await.

– func capture(), takes a picture with the current camera settings and returns it as an image. Call with await.

– Zoom, (basically, FOV) you could bind this to a scroll action!

– Focal Distance (where the depth of feild is focused on)

– Fstop

– Shutter Speed

– ISO

– Aspect Ratio

– You may want to let the player enable/disable some of the overlays in the “Drawing” section

Let me know if you encounter any issues or if you make any games with this! But please be nice 🙏

Shader code

shader_type canvas_item;

uniform sampler2D screen_texture : hint_screen_texture, filter_linear_mipmap;
uniform vec2 resolution = vec2(1920, 1080);

group_uniforms Camera_Settings;
uniform float iso : hint_range(100, 25600, 100) = 400;
uniform float fstop : hint_range(1.0, 32.0, 0.1) = 2.8;
uniform float shutter_speed : hint_range(0.016667, 4.0, 0.0001) = 0.004;
uniform float set_ev : hint_range(-5.0, 5.0, 0.001) = 0.0;

group_uniforms Exposure;
uniform float base_ev = 17.621;

group_uniforms MotionBlur;
uniform bool motion_blur_enabled = false;
uniform vec2 blur_direction = vec2(0.0, 0.0);
uniform int samples : hint_range(4, 32) = 32;

group_uniforms Noise_Settings;
uniform float noise_intensity : hint_range(0, 1.0, 0.001) = 0.5;
uniform float max_noise : hint_range(0.1, 2.0, 0.001) = 1.0;

group_uniforms Red;
uniform float r_intensity : hint_range(0, 2.0, 0.001) = 1.0;
uniform float r_scale : hint_range(0.1, 0.6, 0.001) = 0.472;

group_uniforms Green;
uniform float g_intensity : hint_range(0, 2.0, 0.001) = 0.667;
uniform float g_scale : hint_range(0.1, 0.6, 0.001) = 0.6;

group_uniforms Blue;
uniform float b_intensity : hint_range(0, 2.0, 0.001) = 1.213;
uniform float b_scale : hint_range(0.1, 0.6, 0.001) = 0.41;

// hash22 random taken from https://www.shadertoy.com/view/lldyDn w/ a seed added
vec2 hash22(vec2 uv, float seed) {
	uv += seed;
	vec3 p3 = fract(vec3(uv.xyx) * vec3(0.1031, 0.1030, 0.0973));
	p3 += dot(p3, p3.yzx + 33.33);
	return fract((p3.xx + p3.yz) * p3.zy) * 2.0 - 1.0;
}

// perlin noise from https://godotshaders.com/snippet/2d-noise/
float noise(vec2 uv, float s) {
	vec2 uv_index = floor(uv);
	vec2 uv_fract = fract(uv);
	vec2 blur = smoothstep(0.0, 1.0, uv_fract);

	return mix(
		mix(dot(hash22(uv_index + vec2(0.0, 0.0), s), uv_fract - vec2(0.0, 0.0)),
			dot(hash22(uv_index + vec2(1.0, 0.0), s), uv_fract - vec2(1.0, 0.0)), blur.x),
		mix(dot(hash22(uv_index + vec2(0.0, 1.0), s), uv_fract - vec2(0.0, 1.0)),
			dot(hash22(uv_index + vec2(1.0, 1.0), s), uv_fract - vec2(1.0, 1.0)), blur.x),
		blur.y) + 0.5;
}

void fragment() {
	vec2 uv = SCREEN_UV;

	// motion blur modified from https://godotshaders.com/shader/3d-camera-smooth-motion-blur/
	vec4 pixel_color;
	if (motion_blur_enabled) {
		vec4 color = vec4(0.0);
		float total_weight = 0.0;

		for (int i = 0; i < samples; i++) {
			float offset = float(i) / float(samples - 1) + 0.5;
			vec2 uv_offset = blur_direction * offset;
			color += texture(screen_texture, uv + uv_offset);
			total_weight += 1.0;
		}

		pixel_color = color / total_weight;
	} else {
		pixel_color = texture(screen_texture, uv);
	}

	// exposure calculation
	uv.y *= resolution.y / resolution.x;

	float light_gathering = (1.0 / (fstop * fstop)) * shutter_speed;
	float scene_ev = set_ev + base_ev + log2(light_gathering * iso / 100.0);
	float exposure_multiplier = pow(2.0, scene_ev - 12.0);

	pixel_color.rgb *= exposure_multiplier;

	// blobby noise using perlin func
	float photon_noise_factor = sqrt(1.0 / max(light_gathering, 0.0001));
	float read_noise_factor = sqrt(iso / 100.0);
	float noise_amplifier = photon_noise_factor * read_noise_factor;

	vec3 delta_color = vec3(
		(noise(uv * resolution.y * r_scale, 1.23 + TIME) - 0.5) * 2.0 * r_intensity,
		(noise(uv * resolution.y * g_scale, 4.32 + TIME) - 0.5) * 2.0 * g_intensity,
		(noise(uv * resolution.y * b_scale, 5.25 + TIME) - 0.5) * 2.0 * b_intensity
	) * noise_intensity * min(noise_amplifier * 0.01, max_noise);

	pixel_color.rgb += delta_color;
	COLOR = pixel_color;
}

Live Preview

Tags
