Seperate Specular Alpha Trick

Normally, ALPHA will change the transparency of both Diffuse and Specular light. There are times we only want Diffuse to become transparent, like when we are making a glass shader.

The solution is very simple, just add blend_premul_alpha as a render mode and multiply your ALBEDO by your transparency uniform! No more unintentional specular darkening! To adjust how much Specular is effected just change the speculars brightness.

Shader code
shader_type spatial;
render_mode blend_premul_alpha; //Add premultiplied alpha

uniform vec3 diffuse : source_color;
uniform float roughness : hint_range(0.0, 1.0, 0.1) = 0.5;
uniform float transparency : hint_range(0.0, 1.0, 0.01) = 1.0;

void fragment() {
	ALBEDO = diffuse * transparency; //multiply diffuse by transparency to make only albedo become transparent!
	ROUGHNESS = roughness;
	ALPHA = transparency;
}
Live Preview
Tags
glass, Transparent
The shader code and all code snippets in this post are under CC0 license and can be used freely without the author's permission. Images and videos, and assets depicted in those, do not fall under this license. For more info, see our License terms.
