Spatial Pixelization/Mosaic

How to use?
1. Create an object that will be the “mask” for pixelization eg. cube
2. Place the object over the geometry that you want pixelized.
3. Apply this shader to the mask object

TAA (and I guess FSR as well, since it is also a temporal effect) doesn’t work well with this shader – if you enable it expect some shimmering on the pixelated parts.

Shader code

shader_type spatial;
render_mode unshaded, depth_draw_always, cull_back, blend_mix;

uniform float pixelation : hint_range(0.001, 0.1) = 0.01;
uniform sampler2D SCREEN_TEXTURE : hint_screen_texture, filter_linear_mipmap;
uniform float opacity : hint_range(0.0, 1.0) = 1.0;

void vertex() {
    POSITION = PROJECTION_MATRIX * MODELVIEW_MATRIX * vec4(VERTEX, 1.0);
}

void fragment() {
    // Calculate pixel dimensions with screen aspect correction
    float aspect = float(VIEWPORT_SIZE.x) / float(VIEWPORT_SIZE.y);
    vec2 pixel_size = vec2(pixelation / aspect, pixelation);

    // Calculate grid aligned UV coordinates
    vec2 coord = SCREEN_UV;

    // Round to nearest pixel boundary to prevent edge shimmer
    coord = (floor(coord / pixel_size) + 0.5) * pixel_size;

    // Add small edge tolerance
    float edge_tolerance = 0.001;
    coord = clamp(coord, pixel_size * 0.5 + edge_tolerance, 1.0 - pixel_size * 0.5 - edge_tolerance);

    // Sample with explicit LOD to prevent mipmap shimmer
    vec4 color = textureLod(SCREEN_TEXTURE, coord, 0.0);

    // Apply anti-alias at edges
    vec2 uv_delta = fwidth(SCREEN_UV);
    vec2 edge_dist = smoothstep(vec2(0.0), uv_delta * 2.0, SCREEN_UV) *
                     smoothstep(vec2(0.0), uv_delta * 2.0, vec2(1.0) - SCREEN_UV);
    float edge_factor = edge_dist.x * edge_dist.y;

    ALBEDO = color.rgb;
    ALPHA = opacity * edge_factor;
}
