Stylized Flame

This shader uses an unconventional method of assigning color bands based on the normals to the camera. This allows the flame to show all of its colors coming from its core no matter what angle its seen from, while also giving it a volumetric appearance.

Instructions:
1. Apply to a sphere or similar smooth mesh.

2. Add a default noise texture from fastnoiselite (seamless)

3. Set the +y axis of the mesh to point in the direction of the flame that you want.

4. Experiment with settings.

Shader code

shader_type spatial;
render_mode cull_disabled, blend_add, unshaded;

//speed of noise scroll
uniform float time_speed = 1.0;
//twisting motion of the flame
uniform float spin = 0.0;
//flame brightness
uniform float flame_brightness = 0.6;
uniform float color_intensity = 0.0;
//affects the frequency of the noise, higher values makes the flame streak vertically
uniform float horizontal_frequency = 1.0;
//affects the frequency of the noise, higher values makes the flame streak vertically(kinda ugly)
uniform float vertical_frequency = 1.0;
//overall size muliplier
uniform float size = -0.3;
//banding bias, affects total size, find balance of core size and size to find ideal band width and size
uniform float core_size = 1.0;
//noise texture
uniform sampler2D noise_texture;
//preset colors
uniform vec4 color1 : source_color = vec4(0.286, 0.22, 0.733, 1.0);  // Core of the flame (orange)
uniform vec4 color2 : source_color = vec4(0.98, 0.38, 0.34, 1.0);
uniform vec4 color3 : source_color = vec4(0.98, 0.95, 0.53, 1.0);
uniform vec4 color4 : source_color = vec4(1.0, 1.0, 1.0, 1.0);

void fragment() {
// Time factor to animate the noise
	float time = TIME * time_speed;

// Calculate dot product between normal and view direction
	float normal_facing = dot(NORMAL, VIEW);
// Calculates the noise value
	float noise_value = texture(noise_texture,vec2(UV.x * horizontal_frequency + spin * (time /2.0), (UV.y * vertical_frequency) + time)).r;
// Adds the noise to the determined normal value
	normal_facing += (noise_value -0.5 + size) * 0.3;
// Band value to be split
	float band = normal_facing * 3.0 * core_size;
	vec4 flame_color = vec4(0,0,0,0);
	if (band <= 1.5) {
		ALPHA = 0.0;
	}
	else if(band <= 2.0){
// This modifies the colors within the bands to be influenced by the next inner band. Makes it look like there is bloom within the bands.
		flame_color = mix(color1, color2, -0.01 / (band-2.01));
	}
	else if (band <= 2.5) {
		flame_color = color2;
		flame_color = mix(color2, color3, -0.01 / (band-2.51));
	}
	else if (band <= 2.9) {
		flame_color = color3;
		flame_color = mix(color3, color4, -0.01 / (band-2.91));
	}
	else if (band >= 0.0) {
		flame_color = color4;

	}
//sets the final color using the brightness and color intensity, helps combat the transparency caused by blend_add
	ALBEDO = flame_brightness * (vec3(1.0, 1.0, 1.0) - (flame_color.xyz * -color_intensity)) * flame_color.xyz;
}
