Advanced Modulate

This shader allows you to color any image in an advanced way without too much trouble
you can get RGB, Saturation, Brightness, Gamma and many other useful parameters to get the best color.
It doesn’t matter if your original image is Green, Red, Purple or other, this Shader allows you to totally change the color of any image.
Easy to use, for an advanced result

Shader code
shader_type canvas_item;

// Controlli RGB
uniform float red_factor : hint_range(0.0, 2.0) = 1.0;
uniform float green_factor : hint_range(0.0, 2.0) = 1.0;
uniform float blue_factor : hint_range(0.0, 2.0) = 1.0;

// Controlli Saturazione, Contrasto, Luminosità e Hue
uniform float saturation : hint_range(0.0, 2.0) = 1.0; // Saturazione
uniform float brightness : hint_range(-1.0, 1.0) = 0.0; // Luminosità
uniform float contrast : hint_range(0.0, 2.0) = 1.0; // Contrasto
uniform float hue_shift : hint_range(-1.0, 1.0) = 0.0; // Shift Tonalità
uniform float gamma : hint_range(0.1, 3.0) = 1.0; // Gamma Correction

// Funzione per convertire da RGB a HSL
vec3 rgb2hsl(vec3 color) {
    float max_color = max(max(color.r, color.g), color.b);
    float min_color = min(min(color.r, color.g), color.b);
    float delta = max_color - min_color;

    float lightness = (max_color + min_color) / 2.0;
    float hue = 0.0;
    float sat = 0.0;  // Rinomina la saturazione locale in 'sat'

    if (delta != 0.0) {
        sat = (lightness < 0.5) ? (delta / (max_color + min_color)) : (delta / (2.0 - max_color - min_color));

        if (max_color == color.r) {
            hue = (color.g - color.b) / delta + (color.g < color.b ? 6.0 : 0.0);
        } else if (max_color == color.g) {
            hue = (color.b - color.r) / delta + 2.0;
        } else {
            hue = (color.r - color.g) / delta + 4.0;
        }

        hue /= 6.0;
    }

    return vec3(hue, sat, lightness);
}

// Funzione per convertire da HSL a RGB
vec3 hsl2rgb(vec3 hsl) {
    float hue = hsl.x;
    float sat = hsl.y;  // Usa 'sat' invece di 'saturation'
    float lightness = hsl.z;

    float chroma = (1.0 - abs(2.0 * lightness - 1.0)) * sat;
    float h = hue * 6.0;
    float x = chroma * (1.0 - abs(mod(h, 2.0) - 1.0));

    vec3 result;

    if (h < 1.0) {
        result = vec3(chroma, x, 0.0);
    } else if (h < 2.0) {
        result = vec3(x, chroma, 0.0);
    } else if (h < 3.0) {
        result = vec3(0.0, chroma, x);
    } else if (h < 4.0) {
        result = vec3(0.0, x, chroma);
    } else if (h < 5.0) {
        result = vec3(x, 0.0, chroma);
    } else {
        result = vec3(chroma, 0.0, x);
    }

    float m = lightness - chroma / 2.0;
    return result + vec3(m, m, m);
}

void fragment() {
    // Prendi il colore della texture
    vec4 tex_color = texture(TEXTURE, UV);

    // Modifica RGB
    tex_color.r *= red_factor;
    tex_color.g *= green_factor;
    tex_color.b *= blue_factor;

    // Converte il colore in HSL
    vec3 hsl = rgb2hsl(tex_color.rgb);

    // Shift del tono (Hue)
    hsl.x = mod(hsl.x + hue_shift, 1.0);

    // Modifica della Saturazione
    hsl.y *= saturation;

    // Riconverti in RGB
    vec3 final_rgb = hsl2rgb(hsl);

    // Applica Luminosità e Contrasto
    final_rgb = final_rgb * contrast + vec3(brightness);

    // Applica la correzione gamma
    final_rgb = pow(final_rgb, vec3(gamma));

    // Assegna il colore finale mantenendo l'alpha originale
    COLOR = vec4(final_rgb, tex_color.a);
}
Tags
Color, recolor
