Cone Step Mapping

ElSuicio May 8, 2026May 8, 2026

Cone step mapping based on the paper by Jonathan “LoneSock” Dummer, “Cone Step Mapping: An Iterative Ray-Heightfield Intersection Algorithm”.

Shader code

// ElSuicio, 2026.
// GODOT v4.6.2.stable.
// x.com/ElSuicio
// github.com/ElSuicio
// Contact email [interdreamsoft@gmail.com]

shader_type spatial;
render_mode skip_vertex_transform;

group_uniforms _Transform;
uniform vec3 _Position = vec3(0.0);
uniform vec3 _Rotation = vec3(0.0);
uniform vec3 _Scale = vec3(1.0);

group_uniforms _Albedo;
uniform vec4 _DiffuseColor : source_color = vec4(1.0);
uniform sampler2D _DiffuseTexture : source_color, filter_nearest_mipmap, repeat_enable;

group_uniforms _Metallic;
uniform float _Metallic : hint_range(0.0, 1.0, 1e-3) = 0.0;
uniform float _Specular : hint_range(0.0, 1.0, 1e-3) = 0.5;
uniform sampler2D _MetallicTexture : hint_default_white, filter_nearest_mipmap, repeat_enable;

group_uniforms _Roughness;
uniform float _Roughness : hint_range(0.0, 1.0, 1e-3) = 1.0;
uniform sampler2D _RoughnessTexture : hint_roughness_r, filter_nearest_mipmap, repeat_enable;

group_uniforms _Emission;
uniform vec4 _EmissionColor : source_color = vec4(vec3(0.0), 1.0);
uniform sampler2D _EmissionTexture : source_color, hint_default_black, filter_nearest_mipmap, repeat_enable;
uniform float _EmissionEnergyMultiplier : hint_range(0.0, 100.0, 1e-3) = 0.0;

group_uniforms _NormalMap;
uniform sampler2D _NormalMap : hint_roughness_normal, filter_nearest_mipmap, repeat_enable;
uniform float _NormalMapScale : hint_range(-16.0, 16.0, 1e-3) = 1.0;

group_uniforms _ConeStepMapping;
uniform float _TextureSide = 2048.0;
uniform sampler2D _ConeStepMap : filter_linear, repeat_enable;
uniform float _HeightScale : hint_range(0.0, 1.0, 1e-3) = 0.0;
uniform float _MaxSteps : hint_range(1.0, 1024.0, 1.0) = 256.0;

group_uniforms _UV;
uniform vec2 _Tiling = vec2(1.0, 1.0);
uniform vec2 _Offset = vec2(0.0, 0.0);

varying mat3 TBN;
varying mat3 TBN_TRANSPOSE;

varying vec2 _parallax_uv;

varying float _parallax_height;
varying float _height_scale;

vec2 tiling_and_offset(
	in vec2 st,
	in vec2 tiling,
	in vec2 offset
)
{
	return vec2(st.x * tiling.x + offset.x, st.y * tiling.y + offset.y);
}

mat4 translation_matrix(
	in vec3 position
)
{
	return mat4(
	vec4(1, 0, 0, 0),
	vec4(0, 1, 0, 0),
	vec4(0, 0, 1, 0),
	vec4(position.x, position.y, position.z, 1)
	);
}

mat4 rotation_matrix(
	in vec3 angle // In radians.
)
{
	mat4 x = mat4(
		vec4(1, 0, 0, 0),
		vec4(0,  cos(angle.x), sin(angle.x), 0),
		vec4(0, -sin(angle.x), cos(angle.x), 0),
		vec4(0, 0, 0, 1)
	);

	mat4 y = mat4(
		vec4(cos(angle.y), 0, -sin(angle.y), 0),
		vec4(0, 1, 0, 0),
		vec4(sin(angle.y), 0,  cos(angle.y), 0),
		vec4(0, 0, 0, 1)
	);

	mat4 z = mat4(
		vec4( cos(angle.z), sin(angle.z), 0, 0),
		vec4(-sin(angle.z), cos(angle.z), 0, 0),
		vec4(0, 0, 1, 0),
		vec4(0, 0, 0, 1)
	);

	// Godot Default Rotation Order (YXZ).
	return y * x * z;
}

mat4 escalation_matrix(
	in vec3 scale
)
{
	return mat4(
	vec4(scale.x, 0, 0, 0),
	vec4(0, scale.y, 0, 0),
	vec4(0, 0, scale.z, 0),
	vec4(0, 0, 0, 1)
	);
}

vec2 step_cone_mapping_exact(
	in vec2 st,
	in vec3 view_ts,
	in sampler2D cone_step_map,
	in float texture_side,
	in float height_scale,
	inout float current_layer_height
)
{
	float w = 1.0 / texture_side;

	float view_lenght = length(view_ts.xy);

	vec4 current_cone_step_map = texture(cone_step_map, st);

	float scale = 0.0;

	while ((1.0 - view_ts.z * scale) > current_cone_step_map.r) {
		scale += w + (1.0 - view_ts.z * scale - current_cone_step_map.r) / (view_ts.z + view_lenght / (current_cone_step_map.g * current_cone_step_map.g));
		current_cone_step_map = texture(cone_step_map, st + view_ts.xy * scale * height_scale);
	}

	current_layer_height = view_ts.z * scale;

	scale -= w;

	return st + view_ts.xy * scale * height_scale;
}

vec2 step_cone_mapping_loop(
	in vec2 st,
	in vec3 view_ts,
	in int max_steps,
	in sampler2D cone_step_map,
	in float texture_side,
	in float height_scale,
	inout float current_layer_height
)
{
	float w = 1.0 / texture_side;

	float view_lenght = length(view_ts.xy);

	vec4 current_cone_step_map = texture(cone_step_map, st);

	float scale = 0.0;

	for (int i = 0; i < max_steps; ++i) {
		if ((1.0 - view_ts.z * scale) <= current_cone_step_map.r) {
			break;
		}

		scale += w + (1.0 - view_ts.z * scale - current_cone_step_map.r) / (view_ts.z + view_lenght / (current_cone_step_map.g * current_cone_step_map.g));
		current_cone_step_map = texture(cone_step_map, st + view_ts.xy * scale * height_scale);
	}

	current_layer_height = view_ts.z * scale;

	scale -= w;

	return st + view_ts.xy * scale * height_scale;
}

float pixel_depth_offset(
	in vec2 base_st,
	in vec3 view_ts,
	in vec3 vertex_vs,
	in float height_scale,
	in float parallax_height,
	in mat3 tbn,
	in mat4 projection_matrix
)
{
	vec3 dpdx = dFdx(vertex_vs);
	vec3 dpdy = dFdy(vertex_vs);

	vec2 dstdx = dFdx(base_st);
	vec2 dstdy = dFdy(base_st);

	float scale_x = length(dpdx) / max(length(dstdx), 1e-5);
	float scale_y = length(dpdy) / max(length(dstdy), 1e-5);

	float mesh_scale = (scale_x + scale_y) * 0.5;

	float height = parallax_height * height_scale * mesh_scale;

	vec3 parallax_offset_ts = view_ts * (height / view_ts.z);
	vec3 parallax_offset_vs = tbn * parallax_offset_ts;

	vec3 disp_pos_vs = vertex_vs - parallax_offset_vs;

	vec4 disp_pos_proj = projection_matrix * vec4(disp_pos_vs, 1.0);
	disp_pos_proj.xyz /= disp_pos_proj.w;

	return disp_pos_proj.z;
}

void vertex()
{
	/* UV */
	UV = tiling_and_offset(UV, _Tiling, _Offset);

	/* Translation */
	mat4 TRANSLATION_MATRIX = translation_matrix(_Position);

	/* Rotation */
	mat4 ROTATION_MATRIX = rotation_matrix(radians(_Rotation));

	/* Scale */
	mat4 ESCALATION_MATRIX = escalation_matrix(_Scale);

	/* Vertex */
	vec4 vertex_os = vec4(VERTEX, 1.0);
	vertex_os = ESCALATION_MATRIX * vertex_os;
	vertex_os = ROTATION_MATRIX * vertex_os;
	vec4 vertex_ws = MODEL_MATRIX * vertex_os;
	vertex_ws = TRANSLATION_MATRIX * vertex_ws;
	vec4 vertex_vs = VIEW_MATRIX * vertex_ws;
	VERTEX = vertex_vs.xyz;

	/* Normal */
	vec4 normal_os = vec4(NORMAL, 0.0);
	normal_os = ROTATION_MATRIX * normal_os;
	vec4 normal_ws = MODEL_MATRIX * normal_os;
	vec4 normal_vs = VIEW_MATRIX * normal_ws;
	NORMAL = normalize(normal_vs.xyz);

	/* Binormal */
	vec4 binormal_os = vec4(BINORMAL, 0.0);
	binormal_os = ROTATION_MATRIX * binormal_os;
	vec4 binormal_ws = MODEL_MATRIX * binormal_os;
	vec4 binormal_vs = VIEW_MATRIX * binormal_ws;
	BINORMAL = normalize(binormal_vs.xyz);

	/* Tangent */
	TANGENT = normalize(cross(BINORMAL, NORMAL));

	/* TBN */
	TBN = mat3(-TANGENT, BINORMAL, NORMAL);
	TBN_TRANSPOSE = transpose(TBN);

	/* Projection */
	vec4 vertex_proj = PROJECTION_MATRIX * vertex_vs;
	POSITION = vertex_proj;
}

void fragment() {
	/* Parallax UV */
	_parallax_uv = UV;

	/* View in Tangent Space */
	vec3 view_ts = TBN_TRANSPOSE * VIEW;

	/* Cone Step Mapping */
	_parallax_height = 0.0;
	_height_scale = _HeightScale * 0.5;

	//_parallax_uv = step_cone_mapping_exact(_parallax_uv, view_ts, _ConeStepMap,  _TextureSide, _height_scale, _parallax_height);
	_parallax_uv = step_cone_mapping_loop(_parallax_uv, view_ts, int(_MaxSteps), _ConeStepMap, _TextureSide, _height_scale, _parallax_height);

	/* Pixel Depth Offset (PDO) */
	DEPTH = pixel_depth_offset(UV, view_ts, VERTEX, _height_scale, _parallax_height, TBN, PROJECTION_MATRIX);

	/* Diffuse Color */
	vec4 albedo = _DiffuseColor * texture(_DiffuseTexture, _parallax_uv);
	ALBEDO = albedo.rgb;
	//ALPHA = albedo.a;

	/* Metallic */
	float metallic = _Metallic * texture(_MetallicTexture, _parallax_uv).b;
	METALLIC = metallic;
	SPECULAR = _Specular;

	/* Roughness */
	float roughness = _Roughness * texture(_RoughnessTexture, _parallax_uv).g;
	ROUGHNESS = roughness;

	/* Emission */
	vec4 emission = _EmissionColor + texture(_EmissionTexture, _parallax_uv); // Emission operator add.
	//vec4 emission = _EmissionColor * texture(_EmissionTexture, _parallax_uv); // Emission operator multiply.
	EMISSION = emission.rgb * _EmissionEnergyMultiplier;

	/* Normal Mapping */
	NORMAL_MAP = texture(_NormalMap, _parallax_uv).xyz;
	NORMAL_MAP_DEPTH = _NormalMapScale;
}

Live Preview

Related shaders

Uniplanar mapping with dithered blending

Kalamster

【Shadow Mapping】ShadowTactics/Desperado/Commando Enemy FOV

JasonKim

SPOM with horizon detection + self shading (Silhouette clipping Parallax Occlusion Mapping + Self shading + Horizon trimming / erosion)

Amose05

2 Comments

Oldest

Newest Most Voted

tentabrobpy

1 month ago

Nice to see an implementation of this, how are you generating the cone map?

ElSuicio

1 month ago

Reply to tentabrobpy

Jonathan “LoneSock” Dummer generates the cone step map on the CPU using this algorithm described in his article (C++):

// Theirs
#include <iostream>
#include <fstream>
#include <cstdlib>
#include <cmath>
#include <vector>

// in-between
#include <corona.h>

using namespace std;

/*
  basically, 99% of all pixels will fall in under 2.0
  (most of the time, on the heightmaps I've tested)
  the question:
  Is reduced resolution worth missing
  the speedup of the slow ones?
*/

const float max_ratio = 1.0;

/*
  And for the cone version, how tolerant am I?
  (and should it be a ratio, tolerance*r^2, or flat?)
*/

const float cone_tol2 = 4.0 / (255.0 * 255.0);

// Do I want the textures to be computed as tileable?
bool x_tileable = true;
bool y_tileable = true;

int main(int argc, char *argv[])
{
  char OutName[1024];
  int FileCounter;
  long TheSize, ScanWidth;
  long width, height;
  float iwidth, iheight;
  long chans;
  corona::Image *image, *outimage;
  unsigned char *Data;
  long tin;
  int wProgress;
  float really_max = 1.0;

  cout << "********** Height Map Processor **********" << endl << endl;

  // Did I get a file name?
  if (argc < 2) {
    // Oops, no file to convert
    cout << "usage: HeightProc input_file" << endl << endl;
    system ("pause");
    return (0);
  }

  for (FileCounter = 1; FileCounter < argc; ++FileCounter) {
    cout << "Converting file #" << FileCounter << endl;

    // OK, open the image file
    image = corona::OpenImage (argv[FileCounter], corona::PF_R8G8B8A8);

    if (!image) {
      cout << "I could not open " << argv[FileCounter] << endl << endl;
      system ("pause");
      return (0);
    }

    cout << "Loading " << argv[FileCounter] << ":" << endl;

    width = image->getWidth ();
    height = image->getHeight ();
    chans = 4; // forced for now (by corona)
    ScanWidth = chans * width;
    TheSize = ScanWidth * height;
    Data = (unsigned char *)(image->getPixels());

    // invert this (used to convert depth-map to height-map)
    if (false) {
      for (int px = 0; px < width*height; ++px) {
        Data[px*chans] = 255 - Data[px*chans];
      }
    }

    iheight = 1.0 / height;
    iwidth = 1.0 / width;

    wProgress = width / 50;

    cout << endl << "The image " << argv[FileCounter] << " has been loaded." << endl;
    cout << " size: " << width << " x " << height << " by " << 32 << " bits" << endl;
    cout << endl << "Computing:" << endl;

    // warning message if the texture is not square
    if (width != height) {
      cout << endl << "Warning: The image is not square! Results not guaranteed!" << endl;
      system ("pause");
    }

    // Redo the best, and save it
    // (only writing formats supported: PNG, TGA)
    // ((and PNG is compressed and has alpha!!))
    strcpy (OutName, argv[FileCounter]);
    strcat (OutName, "-step.png");
    tin = clock ();

    // pre-processing: compute derivatives
    cout << "Calculating derivatives [";

    for (int y = 0; y < height; ++y) {
      // progress report: works great...if it's square!
      if (y % wProgress == 0) {
        cout << ".";
      }

      for (int x = 0; x < width; ++x) {
        int der;

        // Blue is the slope in x
        if (x == 0) {
          der = (Data[y*ScanWidth + chans*(x+1)] - Data[y*ScanWidth + chans*(x)]) / 2;
        } else if (x == width - 1) {
          der = (Data[y*ScanWidth + chans*(x)] - Data[y*ScanWidth + chans*(x-1)]) / 2;
        } else {
          der = Data[y*ScanWidth + chans*(x+1)] - Data[y*ScanWidth + chans*(x-1)];
        }

        Data[y*ScanWidth + chans*x + 2] = 127 + der / 2;

        // Alpha is the slope in y
        if (y == 0) {
          der = (Data[(y+1)*ScanWidth + chans*x] - Data[(y)*ScanWidth + chans*x]) / 2;
        } else if (y == height - 1) {
          der = (Data[(y)*ScanWidth + chans*x] - Data[(y-1)*ScanWidth + chans*x]) / 2;
        } else {
          der = (Data[(y+1)*ScanWidth + chans*x] - Data[(y-1)*ScanWidth + chans*x]);
        }

        // And the sign of Y will be reversed in OpenGL
        Data[y*ScanWidth + chans*x + 3] = 127 - der / 2;
      }
    }

    cout << "]" << endl;

    // OK, do the processing
    for (int y = 0; y < height; ++y) {
      cout << "img " << (argc - FileCounter) << ": line " << (height - y) << " [";

      for (int x = 0; x < width; ++x) {
        float min_ratio2, actual_ratio;
        int x1, x2, y1, y2;
        float ht, dhdx, dhdy, r2, h2;

        if ((x % wProgress) == 0) {
          cout << ".";
        }

        // set up some initial values
        // (note I'm using ratio squared throughout,
        // and taking sqrt at the end...faster)
        min_ratio2 = max_ratio * max_ratio;

        // information about this center point
        ht = Data[y*ScanWidth + chans*x] / 255.0;
        dhdx = +(Data[y*ScanWidth + chans*x + 2] / 255.0 - 0.5) * width;
        dhdy = -(Data[y*ScanWidth + chans*x + 3] / 255.0 - 0.5) * height;

        // scan in outwardly expanding blocks
        // (so I can stop if I reach my minimum ratio)
        for (
          int rad = 1;
          (rad*rad <= 1.1*1.1*(1.0-ht)*(1.0-ht)*min_ratio2*width*height) &&
          (rad <= 1.1*(1.0-ht)*width) && (rad <= 1.1*(1.0-ht)*height);
          ++rad
        ) {
          // ok, for each of these lines...

          // West
          x1 = x - rad;

          while (x_tileable && (x1 < 0)) {
            x1 += width;
          }

          if (x1 >= 0) {
            float delx = -rad*iwidth;

            // y limits
            // (+- 1 because I'll cover the corners in the X-run)
            y1 = y - rad + 1;

            if (y1 < 0) {
              y1 = 0;
            }

            y2 = y + rad - 1;

            if (y2 >= height) {
              y2 = height - 1;
            }

            // and check the line
            for (int dy = y1; dy <= y2; ++dy) {
              float dely = (dy-y)*iheight;
              r2 = delx*delx + dely*dely;
              h2 = Data[dy*ScanWidth + chans*x1] / 255.0 - ht;

              if ((h2 > 0.0) && (h2*h2 * min_ratio2> r2)) {
                // this is the new (lowest) value
                min_ratio2 = r2 / (h2 * h2);
              }
            }
          }

          // East
          x2 = x + rad;

          while (x_tileable && (x2 >= width)) {
            x2 -= width;
          }

          if (x2 < width) {
            float delx = rad*iwidth;

            // y limits
            // (+- 1 because I'll cover the corners in the X-run)
            y1 = y - rad + 1;

            if (y1 < 0) {
              y1 = 0;
            }

            y2 = y + rad - 1;

            if (y2 >= height) {
              y2 = height - 1;
            }

            // and check the line
            for (int dy = y1; dy <= y2; ++dy) {
              float dely = (dy-y)*iheight;
              r2 = delx*delx + dely*dely;
              h2 = Data[dy*ScanWidth + chans*x2] / 255.0 - ht;

              if ((h2 > 0.0) && (h2*h2 * min_ratio2> r2)) {
                // this is the new (lowest) value
                min_ratio2 = r2 / (h2 * h2);
              }
            }
          }

          // North
          y1 = y - rad;

          while (y_tileable && (y1 < 0)) {
            y1 += height;
          }

          if (y1 >= 0) {
            float dely = -rad*iheight;

            // y limits
            // (+- 1 because I'll cover the corners in the X-run)
            x1 = x - rad;

            if (x1 < 0) {
              x1 = 0;
            }

            x2 = x + rad;

            if (x2 >= width) {
              x2 = width - 1;
            }

            // and check the line
            for (int dx = x1; dx <= x2; ++dx) {
              float delx = (dx-x)*iwidth;
              r2 = delx*delx + dely*dely;
              h2 = Data[y1*ScanWidth + chans*dx] / 255.0 - ht;

              if ((h2 > 0.0) && (h2*h2 * min_ratio2> r2)) {
                // this is the new (lowest) value
                min_ratio2 = r2 / (h2 * h2);
              }
            }
          }

          // South
          y2 = y + rad;

          while (y_tileable && (y2 >= height)) {
            y2 -= height;
          }

          if (y2 < height) {
            float dely = rad*iheight;

            // y limits
            // (+- 1 because I'll cover the corners in the X-run)
            x1 = x - rad;

            if (x1 < 0) {
              x1 = 0;
            }

            x2 = x + rad;

            if (x2 >= width) {
              x2 = width - 1;
            }

            // and check the line
            for (int dx = x1; dx <= x2; ++dx) {
              float delx = (dx-x)*iwidth;
              r2 = delx*delx + dely*dely;
              h2 = Data[y2*ScanWidth + chans*dx] / 255.0 - ht;

              if ((h2 > 0.0) && (h2*h2 * min_ratio2> r2)) {
                // this is the new (lowest) value
                min_ratio2 = r2 / (h2 * h2);
              }
            }
          }
          //done with the expanding loop
        }
        /********** CONE VERSION **********/
        // actually I have the ratio squared. Sqrt it
        actual_ratio = sqrt (min_ratio2);
        // here I need to scale to 1.0
        actual_ratio /= max_ratio;
        // most of the data is on the low end...sqrting again spreads it better
        // (plus multiply is a cheap operation in shaders!)
        actual_ratio = sqrt (actual_ratio);

        // Red stays height
        // Blue remains the slope in x
        // Alpha remains the slope in y

        // but Green becomes Step-Cone-Ratio
        Data[y*ScanWidth + chans*x + 1] = static_cast<unsigned char>(255.0 * actual_ratio + 0.5);

        // but make sure it is > 0.0, since I divide by it in the shader
        if (Data[y*ScanWidth + chans*x + 1] < 1) {
          Data[y*ScanWidth + chans*x + 1] = 1;
        }
      }
      cout << "]" << endl;
    }
    // end my timing after the computation phase
    tin = clock() - tin;
    cout << "Processed in " << tin * 0.001 << " seconds" << endl << endl;

    outimage = corona::CreateImage(width, height, corona::PF_R8G8B8A8, Data);
    if (outimage != NULL) {
      tin = clock();
      cout << "Saved: " << OutName << " " <<
      corona::SaveImage (OutName, corona::FF_PNG, outimage) << endl;
      tin = clock() - tin;
      cout << "(That took " << tin * 0.001 << " seconds)" << endl;
    } else {
      cout << "Couldn't create the new image" << endl;
    }

    // Report
    cout << endl << endl;

  } // and finish all file names passed in

  /*
    cout << "really_max = " << really_max << endl;
    system ("pause");
  */

  // And end it
  cout << endl << "Done processing the image(s)." << endl;

  //system("PAUSE");
  return(0);
}

However, it can be quite slow, so you can use my implementation. You’ll need OpenGL v4.3+ Core and Glad2. I’ll be releasing a cone map generator for Godot soon.

Compute Shader (GLSL):

#version 430

layout(local_size_x = 16, local_size_y = 16) in;

layout(std430, binding = 0) buffer DataBuffer {
	uint data[];
};

const float inv_255 = 1.0 / 255.0;

const float max_ratio = 1.0;

const float tolerance = 1.1;
const float tolerance2 = tolerance * tolerance;

uniform int side;
uniform int side2;

void main()
{
	int x = int(gl_GlobalInvocationID.x);
	int y = int(gl_GlobalInvocationID.y);

	if (x >= side || y >= side) {
		return;
	}

	int idx = y * side + x;

	float height = float((data[idx] >> 0) & 0xFFu) * inv_255;

	float lheight = float((data[y * side + max(x - 1, 0)] >> 0) & 0xFFu) * inv_255;
	float rheight = float((data[y * side + min(x + 1, side - 1)] >> 0) & 0xFFu) * inv_255;

	float uheight = float((data[max(y - 1, 0) * side + x] >> 0) & 0xFFu) * inv_255;
	float dheight = float((data[min(y + 1, side - 1) * side + x] >> 0) & 0xFFu) * inv_255;

	float inv_side = 1.0 / float(side);

	float depth = 1.0 - height;
	float depth2 = depth * depth;

	int x_left, x_right, y_up, y_down;

	float x_offset, y_offset, dhdx, dhdy;

	float min_ratio2 = max_ratio * max_ratio;
	float current_ratio = 0.0;

	for (int r = 1; float(r) * float(r) <= tolerance2 * depth2 * min_ratio2 * float(side2) && r <= tolerance * depth * float(side); ++r) {
		// Left.

		x_left  = (x + side - r) % side;

		x_offset = -float(r) * inv_side;

		y_up = max(y - r + 1, 0);
		y_down = min(y + r - 1, side - 1);

		for (int delta_y = y_up; delta_y <= y_down; ++delta_y) {
			y_offset = float(delta_y - y) * inv_side;
			float distance2 = x_offset * x_offset + y_offset * y_offset;

			float delta_height = float((data[delta_y * side + x_left] >> 0) & 0xFFu) * inv_255 - height;

			if (delta_height > 0.0) {
				float delta_height2 = delta_height * delta_height;

				if (delta_height2 * min_ratio2 > distance2) {
					min_ratio2 = distance2 / delta_height2;
				}
			}
		}

		// Right.

		x_right = (x + r) % side;

		x_offset = float(r) * inv_side;

		y_up = max(y - r + 1, 0);
		y_down = min(y + r - 1, side - 1);

		for (int delta_y = y_up; delta_y <= y_down; ++delta_y) {
			y_offset = float(delta_y - y) * inv_side;
			float distance2 = x_offset * x_offset + y_offset * y_offset;

			float delta_height = float((data[delta_y * side + x_right] >> 0) & 0xFFu) * inv_255 - height;

			if (delta_height > 0.0) {
				float delta_height2 = delta_height * delta_height;
				if (delta_height2 * min_ratio2 > distance2) {
					min_ratio2 = distance2 / delta_height2;
				}
			}
		}

		// Up.

		y_up = (y + side - r) % side;

		y_offset = -float(r) * inv_side;

		x_left  = max(x - r, 0);
		x_right = min(x + r, side - 1);

		for (int delta_x = x_left; delta_x <= x_right; ++delta_x) {
			x_offset = float(delta_x - x) * inv_side;

			float distance2 = x_offset * x_offset + y_offset * y_offset;

			float delta_height = float((data[y_up * side + delta_x] >> 0) & 0xFFu) * inv_255 - height;

			if (delta_height > 0.0) {
				float delta_height2 = delta_height * delta_height;

				if (delta_height2 * min_ratio2 > distance2) {
					min_ratio2 = distance2 / delta_height2;
				}
			}
		}

		// Down.

		y_down = (y + r) % side;

		y_offset = float(r) * inv_side;

		x_left  = max(x - r, 0);
		x_right = min(x + r, side - 1);

		for (int delta_x = x_left; delta_x <= x_right; ++delta_x) {
			x_offset = float(delta_x - x) * inv_side;

			float distance2 = x_offset * x_offset + y_offset * y_offset;

			float delta_height = float((data[y_down * side + delta_x] >> 0) & 0xFFu) * inv_255 - height;

			if (delta_height > 0.0) {
				float delta_height2 = delta_height * delta_height;

				if (delta_height2 * min_ratio2 > distance2) {
					min_ratio2 = distance2 / delta_height2;
				}
			}
		}
	}

	current_ratio = sqrt(min_ratio2);

	current_ratio /= max_ratio;

	current_ratio = sqrt(current_ratio);

	data[idx] = (data[idx] & ~(0xFFu << 8)) | (max(uint(255.0 * current_ratio + 0.5), 1u) << 8);

	// dhdx.

	if (x == 0) {
		dhdx = (rheight - height) * 0.5;
	}
	else if (x == side - 1) {
		dhdx = (height - lheight) * 0.5;
	}
	else {
		dhdx = (rheight - lheight);
	}

	data[idx] = (data[idx] & ~(0xFFu << 16)) | (uint(clamp((dhdx * 0.5 + 0.5) * 255.0, 0.0, 255.0)) << 16);

	// dhdy.

	if (y == 0) {
		dhdy = (dheight - height) * 0.5;
	}
	else if (y == side - 1) {
		dhdy = (height - uheight) * 0.5;
	}
	else {
		dhdy = (dheight - uheight);
	}

	data[idx] = (data[idx] & ~(0xFFu << 24)) | (uint(clamp((-dhdy * 0.5 + 0.5) * 255.0, 0.0, 255.0)) << 24);
}

On my Quadro RTX 4000 GPU for a texture of:
1024 * 1024 – 2476318700 ns
2048 * 2048 – 9084063900 ns

Cone Step Mapping

Shader code

Live Preview

Tags

More from ElSuicio

Diffuse Proxima + Specular Schlick-GGX | The Callisto Protocol Lighting Model

Disney PBS Lighting Model – Slice

Disney PBS Lighting Model

Related shaders

Uniplanar mapping with dithered blending

【Shadow Mapping】ShadowTactics/Desperado/Commando Enemy FOV

SPOM with horizon detection + self shading (Silhouette clipping Parallax Occlusion Mapping + Self shading + Horizon trimming / erosion)
