Distortion based on noise + texture

Simple distortion effect that is based on a noise texture and takes the shape of another one.

alpha -> transparency of the entire effect

albedo_texture -> shape texture

noise_texture -> noise of the distortion

speed -> speed of the noise scroll

distortion -> amount of distortion

Shader code
shader_type spatial;
render_mode unshaded,cull_disabled;

uniform float alpha : hint_range(0.0, 1.0) = 0.0;
uniform sampler2D albedo_texture : source_color, filter_linear,repeat_disable;
uniform sampler2D SCREEN_TEXTURE : hint_screen_texture, filter_nearest,repeat_disable;

uniform sampler2D noise_texture;

uniform float speed : hint_range(0.0, 2.0, 0.005) = 0.5;
uniform float distortion : hint_range(0.0, 0.3, 0.005) = 0.03;

uniform vec3 uv1_scale = vec3(1,1,1);
uniform vec3 uv1_offset;


void vertex() {
	UV=UV*uv1_scale.xy+uv1_offset.xy;

}

void fragment() {
	vec2 noiseValue  = (texture(noise_texture, UV + (TIME * speed)).rg * 2.0) - 1.0; // Range: -1.0 to 1.0

	vec2 noiseDistortion = (noiseValue * distortion);

	vec4 color = texture(SCREEN_TEXTURE, SCREEN_UV + noiseDistortion);

    ALBEDO = vec3(color.rgb);
	ALPHA = alpha * texture(albedo_texture, UV).r;
}


Tags
3d, distortion, mesh, noise, Spatial, texture, uv
The shader code and all code snippets in this post are under CC0 license and can be used freely without the author's permission. Images and videos, and assets depicted in those, do not fall under this license. For more info, see our License terms.
