Liquid In Mesh

Demo:  https://github.com/niceandgoodonline/Liquid-In-Mesh-Shader-Demo-Godot

Port of https://github.com/Lexpartizan/Lexpartizan_godot-bootle-shader to Godot 4.X (Demo made in 4.2 beta 5)

Small tweaks here and there, including sperating the script which tracks spatial activity into a runtime and tool version as well as moving all shader configuration over to the shader material.

The shader code doesn’t do much without the gdscript to track spatial activity. There was some suspecious code in auto-converted spatial activity script, such as `accell_3d = [positions] / delta / detal` inside of `_physics_process()` which I replaced with their constant equivalents.

There maybe other bits in the spatial activity script to optimize/cull, but I didnt look into it that deeply.

Minor features added like toggling bubbles and ramping to a specific color instead of white. For production I would recommend splitting the bubble logic into their own shaders (no bubbles, always bubbles, velocity bubbles etc).

Shader code

shader_type spatial;
render_mode cull_disabled, shadows_disabled;

group_uniforms PhysicsSetByScript;
uniform vec2 coeff; // Coefficients of the linear function for the surface.
uniform float vel; // Rate of change of the coefficients.

group_uniforms Visuals;
uniform vec4 liquid_color     : source_color = vec4(0.7, 0.1, 0.6, 1.0);
uniform vec4 foam_color       : source_color = vec4(0.9f, 0.3, 0.8, 1.0);
uniform float foam_line       : hint_range(0.0, 1.0, 0.001) = 0.2;
uniform float fill_amount     : hint_range(0.0, 1.0, 0.001) = 0.5;
uniform vec2 size             = vec2(1.0, 1.0);
uniform float glass_thickness = 0.05;
uniform float scale           = 1.0;
uniform float wave_intensity  = 0.05f;
uniform sampler2D waves_noise;

group_uniforms Bubbles;
uniform bool HasBubbles     = true;
uniform bool AlwaysBubbles  = false;
uniform float BubbleStrength: hint_range(0.0, 1.0, 0.001) = 0.5;
uniform float BubbleMask    : hint_range(0.0, 1.0, 0.001) = 0.5;
uniform vec2 BubbleSpeed    = vec2(3.0, 3.0);
uniform sampler2D bubbles_tex;

varying lowp vec3 pos;
varying lowp float rot_scale;
varying lowp vec3 world_vec_up_to_model;
varying lowp vec3 weights;

void vertex() {
	VERTEX                -= glass_thickness * NORMAL;
	/* Position inside container rotated to world. */
	pos                   = mat3(MODEL_MATRIX)*VERTEX;
	/* Lerp between height and width depending on world orientation of z axis. */
	world_vec_up_to_model = vec3(0.0f, 1.0f, 0.0f)* mat3(MODEL_MATRIX);
	rot_scale             = mix(size.x, size.y, abs(dot(world_vec_up_to_model, vec3(0.0f, 1.0f, 0.0f))));
	weights               = mat3(MODEL_MATRIX)*NORMAL; weights*=weights;
}

void fragment() {
	/* Set liquid line to fill amount, add noise waves and incline. */
	lowp float wave_noise_1 = texture(waves_noise, (2.0 * pos.xz + 0.5 * TIME * vec2(1.0, 1.0)) * scale).r;
	lowp float wave_noise_2 = texture(waves_noise, (2.0 * pos.xz - 0.5 * TIME * vec2(1.0, 1.0)) * scale).g;
	lowp float wave = wave_intensity * length(coeff) * (wave_noise_1 - 0.5f + wave_noise_2 - 0.5f) + dot(pos.xz, coeff);
	wave *= smoothstep(0.05, 0.25, fill_amount);
	lowp float liquid_line = (fill_amount * 2.0 - 1.0 + wave) * rot_scale;
	if (pos.y > liquid_line) discard;// Discard all vertices above the liquid line. */

	if (HasBubbles){
		float bubble_weight = vel;
		if (AlwaysBubbles) {
			bubble_weight = BubbleStrength;
		}
		vec2 distortion  = vec2(wave_noise_1, wave_noise_2)*0.01;
		lowp vec2 bubbles;
		bubbles.x        = smoothstep(BubbleMask, 1.0, texture(bubbles_tex, scale * BubbleSpeed * pos.yx + distortion - TIME * vec2(2.0, 0.5)).r);
		bubbles.y        = smoothstep(BubbleMask, 1.0, texture(bubbles_tex, scale * BubbleSpeed * pos.yz + distortion - TIME * vec2(2.0, 0.0)).r);
		bubbles         *= weights.zx * 1.0 * bubble_weight;
		BACKLIGHT.z      = bubbles.x + bubbles.y;
	}

	if (FRONT_FACING)
	{
		float foam       = smoothstep(liquid_line - foam_line * scale * rot_scale, liquid_line,pos.y);
		vec3 normal_foam = mix (NORMAL, vec3(coeff.x, 1.0, coeff.y), foam);
		vec3 color_foam  = mix(liquid_color.xyz, foam_color.xyz, foam);
		ALBEDO           = mix(liquid_color.xyz, color_foam, vel);
		NORMAL           = mix(NORMAL, normal_foam, vel);
	}
	else
	{
		ALBEDO = mix(liquid_color.xyz, foam_color.xyz, vel);
		NORMAL = vec3(coeff.x, 1.0, coeff.y);
	}
}

void light()
{
	// Liquid "glow" when held against light.
	lowp float d  = dot(-VIEW, LIGHT);
	lowp float dd = smoothstep(0.0, 1.0, d);
	dd *= dd;
	DIFFUSE_LIGHT = (dd -BACKLIGHT.z * d) * liquid_color.rgb;
}
