Local Space Y-Billboard Shader

This shader uses a modified version of the StandardMaterial3D’s Y-Billboard option, which is normally restricted to the world-space Y axis. This allows for the option to create billboards that rotate along the node’s local Y axis instead.

Shader code
shader_type spatial;
render_mode blend_add,cull_disabled,unshaded;
uniform vec4 albedo : source_color;
uniform sampler2D texture_albedo : source_color,repeat_enable;


void vertex() {
	vec3 local_up = MODEL_MATRIX[1].xyz;
	//cross of:
	//	local_transform.basis.y     and    to_world(view_space.forward)
	//normalized
	//(represents right direction)
	vec4 ax = vec4(normalize(cross(local_up, INV_VIEW_MATRIX[2].xyz)), 0.0);
	//local_transform.basis.y
	//(represents up direction)
	vec4 ay = vec4(local_up.xyz, 0.0);
	//cross of:
	//	to_world(view_space.right)    and    local_transform.basis.y
	//(represents forward direction)
	vec4 az = vec4(normalize(cross(INV_VIEW_MATRIX[0].xyz, local_up)), 0.0);
	MODELVIEW_MATRIX = VIEW_MATRIX * mat4(ax, ay, az, MODEL_MATRIX[3]);
	MODELVIEW_NORMAL_MATRIX = mat3(MODELVIEW_MATRIX);
}

void fragment() {
	vec2 base_uv = UV;
	vec4 albedo_tex = texture(texture_albedo,base_uv);
	ALBEDO = albedo.rgb * albedo_tex.rgb;
	ALPHA = albedo_tex.a * albedo.a;
}
Tags
3d sprite, billboard, billboards, cylindrical, vfx, y axis
The shader code and all code snippets in this post are under CC0 license and can be used freely without the author's permission. Images and videos, and assets depicted in those, do not fall under this license. For more info, see our License terms.
