RingCountdownShader

Circular Countdown Ring Shader

This shader renders a clean, radial progress ring that can shrink clockwise starting from the 12 o’clock position. It’s ideal for UI cooldown indicators, timer rings, charging animations, loading wheels, or any circular progress visualization.
The ring thickness, radius, fade visibility and countdown progress are fully adjustable, making the effect flexible for both gameplay and UI use.

Parameters:

• ring_radius: Base radius of the circular ring

• ring_width: Thickness of the ring border

• ring_color: Tint color applied to the ring

• ring_fade: Global visibility of the ring (0.0 = hidden, 1.0 = full)

• ring_countdown: Countdown progress from 1.0 (complete) to 0.0 (fully depleted clockwise

Shader code

shader_type canvas_item;

uniform float ring_radius : hint_range(0.0, 1.0) = 0.3;           // 圆环半径（相对于UV[-1,1]空间）
uniform float ring_width : hint_range(0.01, 0.2) = 0.05;          // 圆环厚度
uniform vec3 ring_color : source_color = vec3(0.6, 0.8, 0.9);     // 圆环颜色
uniform float ring_fade : hint_range(0.0, 1.0) = 1.0;             // 显隐渐变（0=隐藏，1=全显）
uniform float ring_countdown : hint_range(0.0, 1.0) = 1.0;        // 1=完整，0=从12点顺时针完全消失



void fragment() {

    // 映射 UV 到 [-1,1]

    vec2 uv = UV * 2.0 - 1.0;

    float dis = length(uv);



    //==============================

    // ① 基础圆环形状

    //==============================

    float ring_shape = smoothstep(ring_radius - ring_width, ring_radius, dis)

                     - smoothstep(ring_radius, ring_radius + ring_width, dis);

    ring_shape *= ring_fade;



    //==============================

    // ② 从 12 点方向开始顺时针逐渐消失

    //==============================

    float angle = atan(-uv.x, -uv.y);     // 12点为0，顺时针递增

    angle = mod(angle, 6.2831853);        // [0, 2π]

    angle /= 6.2831853;                   // 映射到 [0,1]

    float countdown_mask = step(angle, ring_countdown);



    //==============================

    // ③ 最终圆环

    //==============================

    float ring_value = ring_shape * countdown_mask;

    vec3 color = ring_color * ring_value;

    float alpha = max(max(color.r, color.g), color.b);

    COLOR = vec4(color, alpha);

}
