SciFi Hologram

A simple tweakeble SciFi  Hologram spatial shader for 3D objects.

  • Heigh customizable
  • Over twelve parameters
  • Full animated
  • Optional textures for more details
  • Flickering
  • Interupts
  • Seperated fresnel color
  • Individual speeds of each part
  • Two diferen scann lines
  • Work with any 3D model
  • GLES3
Shader code
shader_type spatial;
render_mode unshaded;

uniform sampler2D texture_image;

uniform mediump vec4 line_color : hint_color = vec4(0.0, 1.0, 0.0, 1.0);
uniform mediump float line_width : hint_range(0, 1) = 0.005;
uniform mediump float line_blur : hint_range(0, 1) = 0.2;
uniform mediump float line_speed : hint_range(-1, 1) = 0.02;
uniform  bool straight_lines = true;

uniform mediump float interrupt_width : hint_range(0, 1) = 0.5;
uniform mediump float interrupt_blur : hint_range(0, 1) = 0.25;
uniform mediump float interrupt_speed : hint_range(-1, 1) = 0.2;

uniform mediump vec4 glow_color : hint_color = vec4(0.5, 0.75, 1.0, 1.0);
uniform lowp float glow_itensity : hint_range(0, 20) = 4.5;
uniform lowp float glow_amount : hint_range(0, 20) = 4.5;
uniform lowp float flickering : hint_range(0, 1) = 0.55;

vec3 fresnel_glow(float amount, float intensity, vec3 color, vec3 normal, vec3 view) {
	return pow((1.0 - dot(normalize(normal), normalize(view))), amount) * color * intensity;
}

void fragment () {
	vec2 canvas;
	if (straight_lines) {
			canvas = SCREEN_UV;
	} else {
		canvas = vec2(VIEW.x, VIEW.y);
	}
	vec2 lines = vec2(clamp(sin((TIME * line_speed + canvas.y) / line_width), line_blur, 1.0 - line_blur), canvas.x);
	vec2 interupts = vec2(clamp(sin((TIME * interrupt_speed + canvas.y) / interrupt_width * 3.0), interrupt_blur, 1.0 - interrupt_blur), canvas.x);

	float flicker = clamp(fract(cos(TIME) * 43758.5453123), flickering, 1.0);
	vec4 imgtex = flicker * line_color * texture(texture_image, lines * interupts);
	vec3 imgtex_color = vec3(imgtex.r, imgtex.g, imgtex.b);
	vec3 fresnel_color = vec3(glow_color.r, glow_color.g, glow_color.b);
	vec3 fresnel = fresnel_glow(glow_amount, glow_itensity, fresnel_color, NORMAL, VIEW);
	ALBEDO = imgtex_color + fresnel;

	//ALBEDO = vec3(imgtex.r, imgtex.g, imgtex.b);
	EMISSION = glow_amount * vec3(glow_color.r, glow_color.g, glow_color.b);
	ALPHA = lines.x * interupts.x;
}
Tags
3d, animated, ctr, display, hologram, sci-fi, scifi, screen
The shader code and all code snippets in this post are under MIT license and can be used freely. Images and videos, and assets depicted in those, do not fall under this license. For more info, see our License terms.
