Simple 2d transition

Simple transition. Animate or change fill amount to see the transition.

To use the shaders simply add your preferred heightmap in the heightMap sampler and animate fill to change the threshold, you can also change the color of the transition.

Examples of heightmaps are provided in screenshots.

Shader code
shader_type canvas_item;

uniform float fill : hint_range(-0.01,1.0) = -0.01;
uniform vec4 color : hint_color;
uniform sampler2D heightMap;

void fragment(){
	float h = texture(heightMap,UV).x;
	h = clamp(floor(h+fill),0.0,1.0);
	COLOR = vec4(color.rgb,color.a*h);
2d, variable
The shader code and all code snippets in this post are under CC0 license and can be used freely without the author's permission. Images and videos, and assets depicted in those, do not fall under this license. For more info, see our License terms.
