Triplanar Retro

Shader code

shader_type spatial;
render_mode blend_mix, depth_draw_opaque, cull_back, diffuse_burley, specular_schlick_ggx, vertex_lighting;

uniform vec4 albedo_ceiling : source_color;
uniform sampler2D texture_albedo_ceiling : source_color, filter_nearest, repeat_enable;

uniform vec4 albedo_wall : source_color;
uniform sampler2D texture_albedo_wall : source_color, filter_nearest, repeat_enable;

uniform vec4 albedo_floor : source_color;
uniform sampler2D texture_albedo_floor : source_color, filter_nearest, repeat_enable;

uniform float ground_threshold : hint_range(0.0, 1.0, 0.01) = 0.8;
uniform float blend_smoothness : hint_range(0.0, 1.0, 0.01) = 0.1; // Controle de suavidade da transição


varying vec3 uv1_triplanar_pos;
varying vec2 uv1;

uniform float uv1_blend_sharpness : hint_range(0.0, 150.0, 0.001);
varying vec3 uv1_power_normal;

uniform vec3 uv1_scale;
uniform vec3 uv1_offset;

varying vec3 vertex_normal;

uniform bool uv_global = true;

void vertex() {
	vertex_normal = NORMAL;
	ROUGHNESS = 0.0;

	vec3 normal = MODEL_NORMAL_MATRIX * NORMAL;

	TANGENT = vec3(0.0, 0.0, -1.0) * abs(normal.x);
	TANGENT += vec3(1.0, 0.0, 0.0) * abs(normal.y);
	TANGENT += vec3(1.0, 0.0, 0.0) * abs(normal.z);
	TANGENT = inverse(MODEL_NORMAL_MATRIX) * normalize(TANGENT);

	BINORMAL = vec3(0.0, 1.0, 0.0) * abs(normal.x);
	BINORMAL += vec3(0.0, 0.0, -1.0) * abs(normal.y);
	BINORMAL += vec3(0.0, 1.0, 0.0) * abs(normal.z);
	BINORMAL = inverse(MODEL_NORMAL_MATRIX) * normalize(BINORMAL);


	uv1_power_normal = pow(abs(normal), vec3(uv1_blend_sharpness));
	if (uv_global){
		uv1_triplanar_pos = (MODEL_MATRIX * vec4(VERTEX, 1.0)).xyz * uv1_scale + uv1_offset;
	}else{
		uv1_triplanar_pos = vec4(VERTEX, 1.0).xyz * uv1_scale + uv1_offset;
	}

	uv1_power_normal /= dot(uv1_power_normal, vec3(1.0));
	uv1_triplanar_pos *= vec3(1.0, -1.0, 1.0);

	uv1 = UV;
}


vec4 triplanar_texture(sampler2D p_sampler, vec3 p_weights, vec3 p_triplanar_pos) {
	vec4 samp = vec4(0.0);
	samp += texture(p_sampler, p_triplanar_pos.xy) * p_weights.z;
	samp += texture(p_sampler, p_triplanar_pos.xz) * p_weights.y;
	samp += texture(p_sampler, p_triplanar_pos.zy * vec2(-1.0, 1.0)) * p_weights.x;


	return samp;
}

const vec4 ZERO = vec4(0.0,0.0,0.0,0.0);


uniform bool use_uv_on_wall = false;
uniform bool use_uv_on_floor = false;
uniform bool use_uv_on_ceiling = false;
void fragment() {


	vec4 albedo_tex_floor = vec4(0.0);
	if(use_uv_on_floor){
		albedo_tex_floor = texture(texture_albedo_floor,UV * uv1_scale.xy + uv1_offset.xy);
	}else{
		albedo_tex_floor = triplanar_texture(texture_albedo_floor, uv1_power_normal, uv1_triplanar_pos);
	}

	vec4 albedo_tex_wall = vec4(0.0);
	if(use_uv_on_wall){
		albedo_tex_wall = texture(texture_albedo_wall,UV * uv1_scale.xy + uv1_offset.xy);
	}else{
		albedo_tex_wall = triplanar_texture(texture_albedo_wall, uv1_power_normal, uv1_triplanar_pos);
	}

	vec4 albedo_tex_ceiling = vec4(0.0);
	if(use_uv_on_ceiling){
		albedo_tex_ceiling = texture(texture_albedo_ceiling,UV * uv1_scale.xy + uv1_offset.xy);
	}else{
		albedo_tex_ceiling = triplanar_texture(texture_albedo_ceiling, uv1_power_normal, uv1_triplanar_pos);
	}

	float blend_factor_floor = smoothstep(ground_threshold - blend_smoothness, ground_threshold + blend_smoothness, vertex_normal.y);
	float blend_factor_cealing = smoothstep(ground_threshold - blend_smoothness, ground_threshold + blend_smoothness, -vertex_normal.y);


	vec4 albedo_tex =  mix(mix(albedo_tex_wall, albedo_tex_floor, blend_factor_floor),albedo_tex_ceiling,blend_factor_cealing);
	vec4 albedo_color = mix(mix(albedo_wall, albedo_floor, blend_factor_floor),albedo_ceiling,blend_factor_cealing);






	ALBEDO = albedo_color.rgb * albedo_tex.rgb;

	METALLIC = 0.0;
	SPECULAR = 0.0;
	ROUGHNESS = 0.0;
}
