2D Glow Screen ( No WorldEnvironment Node )
create a canvas layer, add a control node to it.
make the control node to full rect. finally add a color rect node that is also full rect and apply the shader to it.
MAKE SURE HDR 2D IS ENABLED IN THE PROJECT SETTINGS
a credit is appreciated.
Sadly, I tried it on web but it did not work. It seems like web builds does not support the bias in texture methods. I opened an issue in godot github to see if they will fix it.
you can check this issue by this link:
https://github.com/godotengine/godot/issues/97943
Shader code
shader_type canvas_item;
uniform sampler2D screen_texture : hint_screen_texture, filter_linear_mipmap_anisotropic, repeat_disable;
uniform float hpass : hint_range(0.0, 1.0, 0.1) = 1.0;
uniform float vpass : hint_range(0.0, 1.0, 0.1) = 1.0;
uniform int radius : hint_range(0, 65, 1) = 65;
render_mode blend_add;
vec4 textureThresholded(sampler2D _texture, vec2 _uv, float _bias) {
vec4 pixel = textureLod(_texture, _uv, _bias);
if ( pixel.r <= 1. && pixel.g <= 1. && pixel.b <= 1. ) {
pixel.rgb = vec3(0.);
}
return pixel;
}
void fragment() {
vec4 pixel = textureThresholded(screen_texture, SCREEN_UV, 0.);
if (radius != 0) {
vec4 blurred = vec4(0., 0., 0., 1.);
float[65] w = {0.0064, 0.0063, 0.0062, 0.0061, 0.006,
0.0059, 0.0058, 0.0057, 0.0056, 0.0055, 0.0054, 0.0053, 0.0052, 0.0051, 0.005, 0.0049, 0.0048, 0.0047, 0.0046, 0.0054, 0.0044, 0.0043, 0.0042, 0.0041, 0.004, 0.0039, 0.0038, 0.0037, 0.0036, 0.0043, 0.0034, 0.0033, 0.0032, 0.0031, 0.003, 0.0029, 0.0028, 0.0027, 0.0026, 0.0052, 0.0024, 0.0023, 0.0022, 0.0021, 0.002, 0.0019, 0.0018, 0.0017, 0.0016, 0.0051, 0.0014, 0.0013, 0.0012, 0.0011, 0.001, 0.0009, 0.0008, 0.0007, 0.0006, 0.0005, 0.0004, 0.0003, 0.0002, 0.0001, 0.};
float px = 1. / float(textureSize(screen_texture, 0).x);
float py = 1. / float(textureSize(screen_texture, 0).y);
for(int i = 0; i < radius; i++) {
float k = float(i + 1);
blurred += textureThresholded(screen_texture, SCREEN_UV + vec2(float(i) * cos(float(i)), 0) * vec2(px, py) * vec2(hpass, vpass), k) * w[i];
blurred += textureThresholded(screen_texture, SCREEN_UV + vec2(float(-i) * cos(float(i)), 0) * vec2(px, py) * vec2(hpass, vpass), k) * w[i];
blurred += textureThresholded(screen_texture, SCREEN_UV + vec2(0, float(i) * sin(float(i))) * vec2(px, py) * vec2(hpass, vpass), k) * w[i];
blurred += textureThresholded(screen_texture, SCREEN_UV + vec2(0, float(-i) * sin(float(i))) * vec2(px, py) * vec2(hpass, vpass), k) * w[i];
blurred += textureThresholded(screen_texture, SCREEN_UV + vec2(float(i) * cos(float(i)), float(i) * sin(float(i))) * vec2(px, py) * vec2(hpass, vpass), k) * w[i];
blurred += textureThresholded(screen_texture, SCREEN_UV + vec2(float(-i) * cos(float(i)), float(-i) * sin(float(i))) * vec2(px, py) * vec2(hpass, vpass), k) * w[i];
blurred += textureThresholded(screen_texture, SCREEN_UV + vec2(float(i) * cos(float(i)), float(-i) * sin(float(i))) * vec2(px, py) * vec2(hpass, vpass), k) * w[i];
blurred += textureThresholded(screen_texture, SCREEN_UV + vec2(float(-i) * cos(float(i)), float(i) * sin(float(i))) * vec2(px, py) * vec2(hpass, vpass), k) * w[i];
blurred += textureThresholded(screen_texture, SCREEN_UV + vec2(float(-i) * cos(float(i)), float(i) * sin(float(i))) * vec2(px, py) * vec2(hpass, vpass), k) * w[i];
blurred += textureThresholded(screen_texture, SCREEN_UV + vec2(float(i) * cos(float(i)), float(-i) * sin(float(i))) * vec2(px, py) * vec2(hpass, vpass), k) * w[i];
}
blurred /= float(radius) / 6.;
pixel += blurred;
} else {
pixel = vec4(0., 0., 0., 1.);
}
COLOR = pixel;
}
so good
Thanks! 😀
It’s not working for me… I set it up as intended, but nothing glows.
You can check the demo project to check what you might have missed.
Besides enabling the HDR 2D setting in the project settings, if you set the color in the editor make sure you set the Color in the RAW tab instead of the RGB / HSV tab so you can set the RGB values to something higher than 1.
I just downloaded the demo project and it really works! Godot 4.3 here.
Can this somehow be modified to work with labels? Really need glowing text, thanks!
for anyone stuck with getting this working, go to project settings, Renderer, Rendering Method, and switch to gl_compatibility
