3-point texture filtering

Very simple port of 3point texture filtering from GLideN64 ( https://github.com/gonetz/GLideN64 ) to the Godot Engine.

Texture’s filtering has to be disabled, otherwise there will be artifacts.

Texture size has to be set manually due to a GLES2 limitation, this can also be used to down or upscale textures non-destructively.

Shader code
// 3 point texture filtering.
// Original author: ArthurCarvalho
// GLSL implementation: twinaphex, mupen64plus-libretro project.
// Ported to Godot by Ed3800

shader_type spatial;
render_mode vertex_lighting, specular_disabled, ambient_light_disabled, shadows_disabled;

uniform sampler2D tex;
uniform vec2 texSize;

void fragment() {
	vec2 offset = fract(UV*texSize - vec2(0.5));
	offset -= step(1.0, offset.x + offset.y);
	vec4 c0 = texture(tex, UV - (offset)/texSize);
	vec2 c1off = vec2(offset.x - sign(offset.x), offset.y);
	vec4 c1 = texture(tex, UV - (c1off)/texSize);
	vec2 c2off = vec2(offset.x, offset.y - sign(offset.y));
	vec4 c2 = texture(tex, UV - (c2off)/texSize);

	ALBEDO = vec4(c0 + abs(offset.x)*(c1-c0) + abs(offset.y)*(c2-c0)).rgb;
}
Tags
filter, filtering, texture, texture filter, texture filtering
The shader code and all code snippets in this post are under GNU GPL v.3 license and can be used freely. Images and videos, and assets depicted in those, do not fall under this license. For more info, see our License terms.
