N64 RDP Texture Filtering Operations

The main goal of this shader code is to attempt to replicate the distinctive visual characteristics of the Nintendo 64’s Texture filtering:

3-Point Bilinear Sampling
“Average” Sampling / “True” Bilinear

ShaderInclude written using angrylion-rdp-plus as a point of reference.
A Simple shader code is included showing how to make use of the filter operations.

ShaderInclude:

ivec2 get_texture_size(sampler2D tex) {
    return textureSize(tex, 0);
}

ivec2 wrap_texel(ivec2 coord, ivec2 size) {
    return ivec2(
        (coord.x % size.x + size.x) % size.x,
        (coord.y % size.y + size.y) % size.y
    );
}

#ifdef FILTER_NONE
vec4 sample_filter(sampler2D tex, vec2 uv) {
    return texture(tex, uv);
}
#endif

#ifdef FILTER_3POINT
vec4 sample_filter(sampler2D tex, vec2 uv) {
    ivec2 texture_size = get_texture_size(tex);
    vec2 pixel_coord_float = uv * vec2(texture_size) - 0.5;

    ivec2 texel_coord = ivec2(floor(pixel_coord_float));
    vec2 frag_coord = fract(pixel_coord_float);

    vec4 t0 = texelFetch(tex, wrap_texel(texel_coord, texture_size), 0);
    vec4 t1 = texelFetch(tex, wrap_texel(texel_coord + ivec2(1, 0), texture_size), 0);
    vec4 t2 = texelFetch(tex, wrap_texel(texel_coord + ivec2(0, 1), texture_size), 0);
    vec4 t3 = texelFetch(tex, wrap_texel(texel_coord + ivec2(1, 1), texture_size), 0);

    if (frag_coord.x + frag_coord.y < 1.0) {
        return t0 + (t1 - t0) * frag_coord.x + (t2 - t0) * frag_coord.y;
    } else {
        vec2 weights = vec2(1.0 - frag_coord.x, 1.0 - frag_coord.y);
        return t3 + (t2 - t3) * weights.x + (t1 - t3) * weights.y;
    }
}
#endif

#ifdef FILTER_BOX
vec4 sample_filter(sampler2D tex, vec2 uv) {
    ivec2 texture_size = get_texture_size(tex);
    vec2 pixel_coord = uv * vec2(texture_size) - 0.5;

    ivec2 texel_coord = ivec2(floor(pixel_coord));
    vec2 f = fract(pixel_coord);

    vec4 t0 = texelFetch(tex, wrap_texel(texel_coord, texture_size), 0);
    vec4 t1 = texelFetch(tex, wrap_texel(texel_coord + ivec2(1, 0), texture_size), 0);
    vec4 t2 = texelFetch(tex, wrap_texel(texel_coord + ivec2(0, 1), texture_size), 0);
    vec4 t3 = texelFetch(tex, wrap_texel(texel_coord + ivec2(1, 1), texture_size), 0);

    return mix(mix(t0, t1, f.x), mix(t2, t3, f.x), f.y);
}
#endif

Shader code

shader_type canvas_item;

// Only one of these should be defined at a time
//#define FILTER_NONE
#define FILTER_3POINT
//#define FILTER_BOX

#include "res://location-to/texture_filter_operations.gdshaderinc"

void fragment() {
    COLOR = sample_filter(TEXTURE, UV);
}
