Animated pattern background

A shader that turns a pattern into an animated background.

Assign it to a ColorRect node and set Anchors Preset to Full Rect to create a background. The color of the ColorRect node will act as the background color, while to color assigned in the ShaderMaterial will be the color of the pattern.

Works well with Kenney’s pattern pack: kenney.nl/assets/pattern-pack-extra

Shader code

shader_type canvas_item;

// Shader for creating an animated pattern background.
// Works well with kenney's pattern pack: https://kenney.nl/assets/pattern-pack-extra

// Assign this shader to a ColorRect node and set "Anchors Preset" to "Full Rect" to create a background.
// Works with other 2D nodes as well.

// Assign the pattern texture here.
// Should be a black and white square texture containing the base pattern.
uniform sampler2D pattern: repeat_enable;
// The color you want the pattern to appear as.
uniform vec4 pattern_color: source_color = vec4(1.0);

// Factor by which UVs are divided.
// Affects the size of each repeating pattern.
uniform float tiling = 100.0;
// How fast the background moves.
uniform vec2 speed = vec2(0.1, 0.5);
// Rotation of the base pattern in a range from -2pi to 2pi.
// You can also use a range from -360 to 360 degrees and convert to radians in the vertex shader.
uniform float rotation: hint_range(-6.28318530717959, 6.28318530717959) = 0.0;

// Compute UVs in the vertex shader and pass them to the fragment shader.
varying vec2 tiled_uv;

// Called for every vertex the material is visible on.
void vertex() {
	// Compute UVs to sample the pattern texture
	// We use VERTEX instead of UV to avoid stretching on rectangular backgrounds
	tiled_uv = VERTEX / tiling + TIME * speed;
	// Apply a rotation using a rotation matrix
	float c = cos(rotation);
	float s = sin(rotation);
	tiled_uv = mat2(vec2(c, -s), vec2(s, c)) * tiled_uv;
}

// Called for every pixel the material is visible on.
void fragment() {
	// Mix the color of the ColorRect with the color of the pattern based on the pattern texture
	// The third parameter is basically the value of the pattern and tells how much of each color to use in the mix
	COLOR = mix(COLOR, pattern_color, texture(pattern, tiled_uv));
}
