Basic Self-shadowing from Heightmap

Basic implementation of self shadowing using a heightmap texture and an arbitrary sun direction. Loosely based on this

Shader code

shader_type spatial;
uniform sampler2D albedo : source_color;
uniform vec4 color : source_color = vec4(1.0);
uniform sampler2D normal : hint_normal;
uniform sampler2D heightmap : source_color;
uniform vec3 light_dir = vec3(0.5, -1.0, 0.2); //light direction
uniform float height_scale = 2.0;
uniform float shadow_strength = 0.8;
uniform int steps = 32; //num of ray steps
uniform float step_size = 0.004; //distance between samples

void fragment() {
    vec3 L = normalize(-light_dir);

    vec2 uv = UV;

    float h = texture(heightmap, uv).r * height_scale;

    vec2 light_uv_dir = normalize(L.xz) * step_size;

    float y_for_1_dist = L.y / length(L.xz);

    float light_height = h;
    float shadow = 1.0;

    //March in light direction
    for (int i = 0; i < steps; i++) {
        uv += light_uv_dir;

        if (uv.x < 0.0 || uv.y < 0.0 || uv.x > 1.0 || uv.y > 1.0)
            break;

        light_height += y_for_1_dist * step_size * 256.0;

        float sample_h = texture(heightmap, uv).r * height_scale;

        if (sample_h > light_height) {
            shadow = 1.0 - shadow_strength;
            break;
        }
    }

	ALBEDO = texture(albedo,UV).rgb * color.rgb * shadow;
	NORMAL_MAP = texture(normal,UV).rgb;
}
