For presets and textures check the grass out here.

Features

• Option to use a 2×2 texture atlas for variation.
• Wind based on noise texture
• Option to have grass blades be billboards.
• Options for smooth, dithering and cut alphas for more control.
• Wind based on a noise texture giving a wavy pattern
• Colors based on a gradient textures.
• Option to randomly pick parts of grass to have different color for highlights.

Usage

This grass shader uses MultiMeshInstance3D as its base.

• If your scene doesn’t already have a ground mesh: Create a MeshInstance3D with your chosen mesh for the ground
• Add another MeshInstance3D with a QuadMesh. This will act as a base for the grass blades.
  • Increase the subdivisions to improve the quality of bending in the wind. Change the size to change the size.
  • You can change the subdivisions and size later as well. It’s also suggested to set the Center Offset Y axis to half your size (This way the pivot of the grass is at the bottom of the blades)

• Add a MultiMeshInstance3D node, and at the top of your viewport select MultiMesh > Populate Surface

• Set your ground mesh as the target, Source mesh as the quad mesh and play with the settings to fit your needs.

• Finally add the shader to the Material Override slot on the MultiMeshInstance3D

Shader code

shader_type spatial;
render_mode blend_mix, depth_prepass_alpha;

uniform bool billboard = false;

uniform sampler2D shape_texture;
uniform sampler2D shape_atlas;
uniform bool use_atlas = false;

group_uniforms Colors;
uniform sampler2D noise_texture;
uniform sampler2D color_gradient;
uniform float random_variation : hint_range(0.0, 1.0, 0.001) = 0.002;

group_uniforms Wind;
uniform sampler2D wind_texture;
uniform vec2 wind_velocity;

group_uniforms Transparency;
uniform float alpha_cut_start : hint_range(0.0, 1.0, 0.05) = 0.1;
uniform float alpha_cut_end : hint_range(0.0, 1.0, 0.05) = 0.9;
uniform int alpha_mode : hint_enum("Smooth", "Dithered", "Cut") = 0;

varying flat int id;
varying vec3 world_pos;

#include "util/dither.gdshaderinc"

vec2 atlas_uv(vec2 uv, int index, int size){
	int tile_count = size * size;
	int i = index % tile_count;
	float x = float(i % size);
	float y = float(i / size);
	vec2 tile_size = 1.0 / vec2(float(size));
	return uv* tile_size + (vec2(x, y) * tile_size);
}

float randomf(int index, int seed){
	float value = sin(float(index + seed)) * 0.5 + 0.5;
	return value;
}

float wind_noise(){
	float value = texture(wind_texture, (world_pos.xz*0.03) - (vec2(TIME * 0.01) * wind_velocity)).r;
	return value;
}

vec3 wind(vec2 uv){
	float wind_noise = wind_noise();
	float wind_affect = pow(1.0 - uv.y, 2.0);
	vec3 value = vec3(
		wind_noise * (wind_velocity.x),
		0.0,
		wind_noise * (wind_velocity.y)) * 0.25;
	value *= wind_affect;
	return value;
}

void vertex() {
	world_pos = (MODEL_MATRIX * vec4(VERTEX, 1.0)).xyz;
	id = INSTANCE_ID;

	if(billboard){
		mat4 billboard_matrix = mat4(
				MAIN_CAM_INV_VIEW_MATRIX[0],
				MAIN_CAM_INV_VIEW_MATRIX[1],
				MAIN_CAM_INV_VIEW_MATRIX[2],
				MODEL_MATRIX[3]);
		MODELVIEW_MATRIX = VIEW_MATRIX * billboard_matrix;

		VERTEX += (VIEW_MATRIX * vec4(wind(UV), 0.0)).xyz;
	} else {
		VERTEX += wind(UV);
	}
	NORMAL = vec3(0.0,1.0,0.0);
}

void fragment() {
	float shape_value = texture(shape_texture, UV).r;
	if(use_atlas){
		vec2 atlas_uv = atlas_uv(UV, id, 2);
		shape_value = texture(shape_atlas, atlas_uv).r;
	}

	float noise_value = texture(noise_texture, world_pos.xz * 0.1).r;
	if(randomf(id,1) < random_variation) noise_value += 0.4;
	vec4 color = texture(color_gradient, vec2(noise_value, 0.0));

	ALBEDO = color.rgb;

	float alpha = shape_value;
	if(alpha_mode == 0){
		ALPHA = alpha;
	} else {
		alpha = clamp((shape_value - alpha_cut_start) / (alpha_cut_end - alpha_cut_start), 0.0, 1.0);
		if(alpha_mode == 1){
			alpha = step(bayer4(FRAGCOORD.xy) + 0.01, alpha);
		}
		if(alpha < 0.1) discard;
	}

}

void light(){
	float ndotl = dot(LIGHT, NORMAL) * ATTENUATION;
	DIFFUSE_LIGHT += ndotl;
}
