Game Boy Palette Overlay

Simple screen texture shader that maps the current screen image to a 4-color output, with an optional palette-constrained brightness slider.

Usage:

  • Add a ColorRect to your scene.
  • Ensure it draws in front of whatever you want to be affected by the palette.
    • For instance, if you want it to cover the whole screen, move it to the end of the hierarchy or make it a “Top Level” CanvasItem, and make its anchor presets “Full Rect”.
  • Add a material with the shader below to it.
  • Set the source_palette and target_palette shader parameters as desired.
    • For a Game Boy look, both should be 4 x 1 pixel .png textures.
    • For ease of use, I recommend the source_palette be an evenly-spaced grayscale:
      • #000000
      • #555555
      • #aaaaaa
      • #ffffff
  • Adjust the brightness value as desired. It can also be quickly tweened to create screen transition effects.

Tip: if you’re stacking screen-reading shaders, you might need to place BackBufferCopy nodes in-between them. Check this article for more information.

Shader code
shader_type canvas_item;

uniform sampler2D screen_texture : hint_screen_texture, repeat_disable, filter_nearest;

uniform float brightness : hint_range(-1, 1) = 0;
uniform sampler2D source_palette;
uniform sampler2D target_palette;

void fragment() {
	vec4 screen_color = texture(screen_texture, SCREEN_UV);
	ivec2 pal_size = textureSize(source_palette, 0);

	float color_diff = 1.0;
	int nearest_swatch = 0;

	for (int swatch=0; swatch < pal_size.x; swatch++) {
		vec4 sampled_color = texelFetch(source_palette, ivec2(swatch,0), 0);
		float new_color_diff = distance(sampled_color, screen_color);

		if (new_color_diff < color_diff) {
			color_diff = new_color_diff;
			nearest_swatch = swatch;
		}
	}

	int swatch_offset = int(brightness * float(pal_size.x));
	int target_swatch = clamp(nearest_swatch + swatch_offset, 0, pal_size.x -1);

	COLOR = texelFetch(target_palette, ivec2(target_swatch, 0), 0);
}
Tags
brightness, gameboy, palette, palette swap, pixel-art, recolor, retro
The shader code and all code snippets in this post are under CC0 license and can be used freely without the author's permission. Images and videos, and assets depicted in those, do not fall under this license. For more info, see our License terms.
