Gradient pixel glint

Pixel glint shader that works with a texture as a glint input, so you can put any colors and gradients there.

Shader code
// CC0, shadecore_dev
shader_type canvas_item;

uniform sampler2D main_color;

uniform float shine_progress : hint_range(0.0, 1.0, 0.01) = 0.0;
uniform float shine_size : hint_range(0.01, 1.0, 0.01) = 0.1;
uniform float shine_angle : hint_range(0.0, 89.9, 0.1) = 45.0;

float scale(float value, float inMin, float inMax, float outMin, float outMax) {
    return (value - inMin) * (outMax - outMin) / (inMax - inMin) + outMin;
}

void fragment() {
	vec2 pixelation = 1.0 / TEXTURE_PIXEL_SIZE;
	vec2 pixelated_uv = floor(UV * pixelation) / pixelation;
	COLOR = texture(TEXTURE, UV);

	float slope = tan(radians(shine_angle));

	float progress = scale(shine_progress, 0.0, 1.0, -1.0 - shine_size - shine_size * slope, 1.0 * slope + shine_size + shine_size * slope);

	float shine_distance = (slope * pixelated_uv.x - pixelated_uv.y - progress) / (sqrt(slope * slope + 1.0));

	float shine_color_coord = clamp((shine_distance / (2.0 * shine_size)) + 0.5, 0.0, 1.0);

	vec4 gradient = texture(main_color, vec2(shine_color_coord, 0.5));

	float shine = step(shine_distance, shine_size) - step(shine_distance, -shine_size);

	COLOR.rgb = mix(COLOR.rgb, gradient.rgb, shine * gradient.a);
}
Live Preview
Tags
2d, glint, pixel, shine
The shader code and all code snippets in this post are under CC0 license and can be used freely without the author's permission. Images and videos, and assets depicted in those, do not fall under this license. For more info, see our License terms.
