Hexagon Highlight Shader for Godot Canvas Items

This shader highlights hexagonal regions on a canvas item in Godot, in the example below it works on a TileMap. It converts each fragment’s position into hexagonal cube coordinates to determine if it falls within a hexagon. If so, the shader blends the original texture color with red at a fixed 50% intensity, but you can do whatever color and intensity you want. Adjust the uniform parameters (hex size, active center, grid offset, and scaling) to fit your project’s grid layout.

Example C# code for testing:

public override void _Process(double delta)
	{
			Vector2 localMousePosition = ToLocal(GetGlobalMousePosition());
			Vector2I tileCoords = LocalToMap(localMousePosition);
			Vector2 centerCoords = MapToLocal(tileCoords);
			Vector2 activeCenter = ToGlobal(centerCoords);


			if (GetCellSourceId(0,tileCoords) != -1)
			{
				Vector2[] hexCenters = new Vector2[3];
				hexCenters[0] = activeCenter;
				hexCenters[1] = activeCenter + new Vector2(120, 0);
				hexCenters[2] = activeCenter + new Vector2(60, 105);
				_shaderMaterial?.SetShaderParameter("num_active_hexes", 3);
				_shaderMaterial?.SetShaderParameter("active_hex_centers", hexCenters);
			}
	}

Example GDScript code for testing:

func _process(delta):
	var local_mouse_position = to_local(get_global_mouse_position())
	var tile_coords = local_to_map(local_mouse_position)
	var center_coords = map_to_local(tile_coords)
	var active_center = to_global(center_coords)

	if get_cell_source_id(0, tile_coords) != -1:
		var hex_centers = [
			active_center,
			active_center + Vector2(120, 0),
			active_center + Vector2(60, 105)
		]
		shader_material.set_shader_parameter("num_active_hexes", 3)
		shader_material.set_shader_parameter("active_hex_centers", hex_centers)

Shader code

shader_type canvas_item;

const int MAX_HEXES = 64;
uniform int num_active_hexes;
uniform vec2 active_hex_centers[MAX_HEXES];

uniform vec2 hex_size = vec2(120.0, 140.0);
uniform vec2 grid_offset = vec2(0.0, 0.0);
uniform float q_scaling = 1.49;
varying vec2 frag_pos;

void vertex() {
    frag_pos = (MODEL_MATRIX * vec4(VERTEX, 0.0, 1.0)).xy;
}

void fragment() {
    // Flag to determine if the current fragment is within any hexagon
    bool insideHex = false;
    for (int i = 0; i < num_active_hexes; i++) {
        // Use grid_offset if needed (for overall grid positioning)
        vec2 hex_center = active_hex_centers[i] + grid_offset;
        vec2 delta = frag_pos - hex_center;

        // Convert to hexagonal cube coordinates with scaling adjustment
        float q = delta.x / (hex_size.x * 0.75) * q_scaling;
        float r = (delta.y - (delta.x / sqrt(3.0))) / (hex_size.y / 2.0);
        float s = -q - r;

        // Check if the fragment is within the hexagon
        float max_distance = max(max(abs(q), abs(r)), abs(s));
        if (max_distance <= 1.0) {
            insideHex = true;
            break;
        }
    }

    vec4 texture_color = texture(TEXTURE, UV);

    // Discard fragments with low alpha
    if (texture_color.a < 0.1) {
        discard;
    }

    // Apply a fixed red highlight mix if inside any hex
    if (insideHex) {
        COLOR = mix(texture_color, vec4(1.0, 0.0, 0.0, 1.0), 0.5);
    } else {
        COLOR = texture_color;
    }
}
