Jolly 1 office with displacement effect

Shader code
shader_type canvas_item;

// the left/right look amount. Ideally clamp this externally to prevent viewing edges
uniform float scroll = 0.0;

// keep positive to maintain pseudo3D effect.
uniform float displacement_scale = 2.0;

// easiest to just make this a curve texture, but making PNG gives a ton of control across the Y axis. Curve texture is just super smooth and doesn't have any issues with tearing.
uniform sampler2D displacement_map : hint_black;

void fragment(){
	vec2 uv = UV + vec2(scroll, 0.0); // scroll the UV
	float displacement = texture(displacement_map, UV).r; // pull amount from map
	displacement *= displacement_scale; // scale
	displacement *= (0.5 - uv.y); // transform based on distance from center horizontal
	COLOR = texture(TEXTURE, uv + vec2(0.0, displacement));// pull source image, displaced by scroll and vertical stretch.
}
The shader code and all code snippets in this post are under CC0 license and can be used freely without the author's permission. Images and videos, and assets depicted in those, do not fall under this license. For more info, see our License terms.
