RTX filter for your game (brightness, ripples and other effects)
You need a shader to make your game brighter and better. If you can’t create an atmosphere using WorldEnvironment, then this shader was created for your use.
Look carefully, it’s not very demanding, but it will make your PC make noise depending on the settings!
Compatible with PC and android devices, but it will be harder to handle on android!
How to use it?
1. Create a 2D object (ColorRect)
2. Just stretch it over the entire window
3. Create a shader material and paste my code…
4. Done!
( For the particularly stupid )
1. Add a 2D node
2. Choose another one or you can ColorRect (recommended)
3. Stretch it out
4. Create a material and select a shader
5. Open the shader code editor (at the bottom)
6. Copy and paste the code
7. Customize for yourself (experiment)
8. I hope it’s clear to you.
Shader code
shader_type canvas_item;
uniform sampler2D SCREEN_TEXTURE : hint_screen_texture, filter_linear_mipmap;
uniform float brightness : hint_range(0.0, 2.0) = 1.0;
uniform float contrast : hint_range(0.0, 2.0) = 1.0;
uniform float saturation : hint_range(0.0, 2.0) = 1.0;
uniform float gamma : hint_range(0.1, 2.2) = 1.0;
uniform float bloom_intensity : hint_range(0.0, 1.0) = 0.2;
uniform float bloom_threshold : hint_range(0.0, 1.0) = 0.6;
uniform float bloom_blur : hint_range(0.0, 10.0) = 4.0;
uniform vec4 tint_color : source_color = vec4(1.0, 0.97, 0.9, 1.0);
uniform float tint_strength : hint_range(0.0, 1.0) = 0.2;
uniform float vignette_intensity : hint_range(0.0, 1.0) = 0.2;
uniform float vignette_opacity : hint_range(0.0, 1.0) = 0.5;
uniform float vignette_roundness : hint_range(0.0, 2.0) = 1.0;
uniform vec4 vignette_color : source_color = vec4(0.0, 0.0, 0.0, 1.0);
uniform float film_grain : hint_range(0.0, 0.5) = 0.03;
uniform float film_grain_speed : hint_range(0.0, 10.0) = 1.0;
uniform float chromatic_aberration : hint_range(0.0, 5.0) = 0.5;
uniform bool enable_god_rays = true;
uniform float god_rays_intensity : hint_range(0.0, 1.0) = 0.1;
uniform vec2 light_position = vec2(0.5, 0.5);
uniform bool enable_lens_dirt = true;
uniform sampler2D lens_dirt_texture : hint_default_white;
uniform float lens_dirt_intensity : hint_range(0.0, 1.0) = 0.5;
uniform bool enable_color_grading = true;
uniform sampler2D color_lut : hint_default_white;
uniform float color_lut_mix : hint_range(0.0, 1.0) = 0.8;
uniform bool enable_dithering = true;
uniform float dithering_intensity : hint_range(0.0, 0.1) = 0.02;
uniform bool enable_scanlines = false;
uniform float scanlines_opacity : hint_range(0.0, 1.0) = 0.2;
uniform float scanlines_width : hint_range(1.0, 20.0) = 10.0;
uniform bool enable_sharpen = true;
uniform float sharpen_intensity : hint_range(0.0, 5.0) = 0.5;
uniform bool enable_color_blindness = false;
uniform int color_blindness_type : hint_range(0, 2) = 0;
uniform float color_blindness_intensity : hint_range(0.0, 1.0) = 1.0;
uniform bool enable_pixelate = false;
uniform float pixelate_amount : hint_range(1.0, 512.0) = 64.0;
uniform bool enable_edge_detection = false;
uniform float edge_detection_intensity : hint_range(0.0, 5.0) = 1.0;
uniform vec4 edge_detection_color : source_color = vec4(0.0, 0.0, 0.0, 1.0);
uniform bool enable_night_vision = false;
uniform vec4 night_vision_color : source_color = vec4(0.0, 1.0, 0.0, 1.0);
uniform float night_vision_noise : hint_range(0.0, 1.0) = 0.3;
vec3 rgb_to_hsv(vec3 rgb) {
float cmax = max(rgb.r, max(rgb.g, rgb.b));
float cmin = min(rgb.r, min(rgb.g, rgb.b));
float delta = cmax - cmin;
vec3 hsv = vec3(0.0, 0.0, cmax);
if (delta > 0.0001) {
hsv.y = delta / cmax;
if (abs(cmax - rgb.r) < 0.0001) {
hsv.x = (rgb.g - rgb.b) / delta + (rgb.g < rgb.b ? 6.0 : 0.0);
} else if (abs(cmax - rgb.g) < 0.0001) {
hsv.x = (rgb.b - rgb.r) / delta + 2.0;
} else {
hsv.x = (rgb.r - rgb.g) / delta + 4.0;
}
hsv.x /= 6.0;
}
return hsv;
}
vec3 hsv_to_rgb(vec3 hsv) {
if (abs(hsv.y) < 0.0001) {
return vec3(hsv.z);
}
float h = hsv.x * 6.0;
int i = int(floor(h));
float f = h - float(i);
float p = hsv.z * (1.0 - hsv.y);
float q = hsv.z * (1.0 - hsv.y * f);
float t = hsv.z * (1.0 - hsv.y * (1.0 - f));
if (i == 0) return vec3(hsv.z, t, p);
else if (i == 1) return vec3(q, hsv.z, p);
else if (i == 2) return vec3(p, hsv.z, t);
else if (i == 3) return vec3(p, q, hsv.z);
else if (i == 4) return vec3(t, p, hsv.z);
else return vec3(hsv.z, p, q);
}
vec3 blur(sampler2D tex, vec2 uv, vec2 resolution, float radius) {
vec3 color = vec3(0.0);
float total = 0.0;
for (float x = -radius; x <= radius; x += 1.0) {
for (float y = -radius; y <= radius; y += 1.0) {
vec2 offset = vec2(x, y) / resolution;
float weight = 1.0 - length(offset) / radius;
if (weight < 0.0) weight = 0.0;
color += texture(tex, uv + offset).rgb * weight;
total += weight;
}
}
return color / total;
}
float random(vec2 uv) {
return fract(sin(dot(uv, vec2(12.9898, 78.233))) * 43758.5453123);
}
vec3 god_rays(sampler2D tex, vec2 uv, vec2 light_pos, float exposure) {
vec3 color = vec3(0.0);
float decay = 0.97;
float density = 0.5;
float weight = 0.3;
vec2 delta = (uv - light_pos) * density / 100.0;
vec2 pos = uv;
for (int i = 0; i < 100; i++) {
pos -= delta;
vec3 sample_color = texture(tex, pos).rgb;
sample_color *= weight * exposure;
color += sample_color;
weight *= decay;
}
return color;
}
float apply_dither_effect(vec2 uv, float color_value) {
float bayer[16] = float[16](
0.0, 8.0, 2.0, 10.0,
12.0, 4.0, 14.0, 6.0,
3.0, 11.0, 1.0, 9.0,
15.0, 7.0, 13.0, 5.0
);
int x = int(mod(uv.x, 4.0));
int y = int(mod(uv.y, 4.0));
float dither_value = bayer[y * 4 + x] / 16.0 - 0.5;
return color_value + dither_value * dithering_intensity;
}
vec3 apply_color_blindness(vec3 color, int type, float intensity) {
mat3 protanopia = mat3(
vec3(0.567, 0.433, 0.0),
vec3(0.558, 0.442, 0.0),
vec3(0.0, 0.242, 0.758)
);
mat3 deuteranopia = mat3(
vec3(0.625, 0.375, 0.0),
vec3(0.7, 0.3, 0.0),
vec3(0.0, 0.3, 0.7)
);
mat3 tritanopia = mat3(
vec3(0.95, 0.05, 0.0),
vec3(0.0, 0.433, 0.567),
vec3(0.0, 0.475, 0.525)
);
mat3 matrix;
if (type == 0) matrix = protanopia;
else if (type == 1) matrix = deuteranopia;
else matrix = tritanopia;
vec3 blind_color = matrix * color;
return mix(color, blind_color, intensity);
}
float edge_detection(sampler2D tex, vec2 uv, vec2 texel_size) {
float offset = 1.0;
vec3 a = texture(tex, uv + texel_size * vec2(-offset, -offset)).rgb;
vec3 b = texture(tex, uv + texel_size * vec2(0.0, -offset)).rgb;
vec3 c = texture(tex, uv + texel_size * vec2(offset, -offset)).rgb;
vec3 d = texture(tex, uv + texel_size * vec2(-offset, 0.0)).rgb;
vec3 f = texture(tex, uv + texel_size * vec2(offset, 0.0)).rgb;
vec3 g = texture(tex, uv + texel_size * vec2(-offset, offset)).rgb;
vec3 h = texture(tex, uv + texel_size * vec2(0.0, offset)).rgb;
vec3 i = texture(tex, uv + texel_size * vec2(offset, offset)).rgb;
vec3 sobel_x = -a - 2.0 * d - g + c + 2.0 * f + i;
vec3 sobel_y = -a - 2.0 * b - c + g + 2.0 * h + i;
float edge = length(sobel_x) + length(sobel_y);
return edge;
}
vec3 sharpen(sampler2D tex, vec2 uv, vec2 texel_size, float intensity) {
vec3 center = texture(tex, uv).rgb;
vec3 top = texture(tex, uv + vec2(0.0, -texel_size.y)).rgb;
vec3 bottom = texture(tex, uv + vec2(0.0, texel_size.y)).rgb;
vec3 left = texture(tex, uv + vec2(-texel_size.x, 0.0)).rgb;
vec3 right = texture(tex, uv + vec2(texel_size.x, 0.0)).rgb;
vec3 sharpen_color = center * (1.0 + 4.0 * intensity) - (top + bottom + left + right) * intensity;
return sharpen_color;
}
vec3 apply_lut(sampler2D lut_texture, vec3 color) {
float blue = color.b * 63.0;
vec2 quad1 = vec2(0.0);
quad1.y = floor(floor(blue) / 8.0);
quad1.x = floor(blue) - (quad1.y * 8.0);
vec2 quad2 = vec2(0.0);
quad2.y = floor(ceil(blue) / 8.0);
quad2.x = ceil(blue) - (quad2.y * 8.0);
vec2 texPos1 = vec2(0.0);
texPos1.x = (quad1.x * 0.125) + 0.0625 + (0.125 * color.r);
texPos1.y = (quad1.y * 0.125) + 0.0625 + (0.125 * color.g);
vec2 texPos2 = vec2(0.0);
texPos2.x = (quad2.x * 0.125) + 0.0625 + (0.125 * color.r);
texPos2.y = (quad2.y * 0.125) + 0.0625 + (0.125 * color.g);
vec3 newColor1 = texture(lut_texture, texPos1).rgb;
vec3 newColor2 = texture(lut_texture, texPos2).rgb;
vec3 newColor = mix(newColor1, newColor2, fract(blue));
return newColor;
}
void fragment() {
vec2 uv = SCREEN_UV;
vec2 pixel_size = 1.0 / SCREEN_PIXEL_SIZE;
if (enable_pixelate) {
vec2 pixelated_uv = floor(uv * pixelate_amount) / pixelate_amount;
uv = pixelated_uv;
}
vec3 color;
if (chromatic_aberration > 0.0001) {
vec2 direction = (uv - 0.5) * 2.0;
vec2 distortion = direction * chromatic_aberration / 1000.0;
color.r = texture(SCREEN_TEXTURE, uv - distortion).r;
color.g = texture(SCREEN_TEXTURE, uv).g;
color.b = texture(SCREEN_TEXTURE, uv + distortion).b;
} else {
color = texture(SCREEN_TEXTURE, uv).rgb;
}
if (enable_sharpen) {
color = sharpen(SCREEN_TEXTURE, uv, 1.0 / pixel_size, sharpen_intensity);
}
if (bloom_intensity > 0.0001) {
vec3 bloom_color = blur(SCREEN_TEXTURE, uv, pixel_size, bloom_blur);
bloom_color = max(bloom_color - bloom_threshold, 0.0);
color += bloom_color * bloom_intensity;
if (enable_lens_dirt && textureSize(lens_dirt_texture, 0).x > 1) {
vec3 dirt = texture(lens_dirt_texture, uv).rgb;
color += bloom_color * dirt * lens_dirt_intensity;
}
}
if (enable_god_rays) {
vec3 rays = god_rays(SCREEN_TEXTURE, uv, light_position, god_rays_intensity * 0.1);
color += rays;
}
if (enable_edge_detection) {
float edge = edge_detection(SCREEN_TEXTURE, uv, 1.0 / pixel_size);
color = mix(color, edge_detection_color.rgb, edge * edge_detection_intensity);
}
color = (color - 0.5) * contrast + 0.5;
color *= brightness;
vec3 hsv = rgb_to_hsv(color);
hsv.y *= saturation;
color = hsv_to_rgb(hsv);
color = pow(color, vec3(1.0 / gamma));
color = mix(color, color * tint_color.rgb, tint_strength);
if (enable_color_grading && textureSize(color_lut, 0).x > 1) {
vec3 graded_color = apply_lut(color_lut, color);
color = mix(color, graded_color, color_lut_mix);
}
if (vignette_intensity > 0.0001) {
vec2 vignette_uv = uv * (1.0 - uv.yx);
float vig = vignette_uv.x * vignette_uv.y * 15.0;
vig = pow(vig, vignette_roundness);
color = mix(color, mix(color, vignette_color.rgb, vignette_opacity), vignette_intensity * (1.0 - vig));
}
if (film_grain > 0.0001) {
float grain = random(uv + vec2(TIME * film_grain_speed * 0.01, TIME * film_grain_speed * 0.01)) * film_grain;
color += grain - film_grain/2.0;
}
if (enable_scanlines) {
float scanline = sin(uv.y * scanlines_width * pixel_size.y) * 0.5 + 0.5;
scanline = pow(scanline, 1.0) * scanlines_opacity;
color = mix(color, color * (1.0 - scanline), scanlines_opacity);
}
if (enable_color_blindness) {
color = apply_color_blindness(color, color_blindness_type, color_blindness_intensity);
}
if (enable_night_vision) {
float luminance = dot(color, vec3(0.299, 0.587, 0.114));
vec3 night_color = vec3(luminance) * night_vision_color.rgb;
float noise = random(uv + vec2(TIME * 0.1, TIME * 0.1)) * night_vision_noise;
night_color += vec3(noise);
float scanline = sin(uv.y * pixel_size.y * 200.0) * 0.1 + 0.9;
night_color *= scanline;
color = night_color;
}
if (enable_dithering) {
color.r = apply_dither_effect(FRAGCOORD.xy, color.r);
color.g = apply_dither_effect(FRAGCOORD.xy, color.g);
color.b = apply_dither_effect(FRAGCOORD.xy, color.b);
}
COLOR = vec4(color, 1.0);
}
Followed your instructions – get a translucent grey overlay (the ColorRect). The effects work under the rect fine, but…
You’re the greatest of all time.
