Screen Space (Canvas) Monotone / Halftone

Just takes the lovely canvas texture monotone shader created by paintsimmon and adjusts it to apply to the screen texture (ie. make it apply to your entire scene view.

As with other scene space shaders, create a CanvasItem with a child ColorRect, set the color rect to fill the screen, and attach this shader to the ColorRect.

Shader code

shader_type canvas_item;

/**
 * Maximum number of dots in one row / column.
 * If the image is not square, the shorter side will have less dots than the maximum.
 */
uniform int max_dots: hint_range(1, 1000, 1) = 800;
/**
 * Bigger number means bigger dots.
 * Inside the shader, it divides the dots by this number.
 */
uniform float dot_size: hint_range(0.0, 10.0, 0.1) = 0.7;
/**
 * Darkens or lightens the whole image uniformly.
 * Larger numbers means lighter and smaller darker.
 * 1.0 is no change.
 */
uniform float brightness_mult: hint_range(0.0, 2.0, 0.1) = 1.0;
/**
 * If enabled, makes the dots the secondary color instead of primary.
 */
uniform bool invert = false;
/**
 * The color used for the dots when invert is disabled and the background when enabled.
 */
uniform vec4 primary_color: source_color = vec4(0.1, 0.1, 0.2, 1);
/**
 * The color used for the background when invert is disabled and the dots when enabled.
 */
uniform vec4 secondary_color: source_color = vec4(0.9, 0.9, 0.8, 1);

uniform sampler2D SCREEN_TEXTURE : hint_screen_texture;


// Converts from RGB to HSV
vec3 rgb2hsv(vec3 tex) {
	vec3 hsv;
	{
		vec3 c = tex;
		vec4 K = vec4(0.0, -1.0 / 3.0, 2.0 / 3.0, -1.0);
		vec4 p = mix(vec4(c.bg, K.wz), vec4(c.gb, K.xy), step(c.b, c.g));
		vec4 q = mix(vec4(p.xyw, c.r), vec4(c.r, p.yzx), step(p.x, c.r));
		float d = q.x - min(q.w, q.y);
		float e = 1.0e-10;
		return tex = vec3(abs(q.z + (q.w - q.y) / (6.0 * d + e)), d / (q.x + e), q.x);
	}
}


void fragment() {
	// Converts max_dots to a float for later use
	float f_max_dots = float(max_dots);
	// Ensures circular dots
	vec2 ratio = vec2(1.0, SCREEN_PIXEL_SIZE.x / SCREEN_PIXEL_SIZE.y);
	// Prevents partial dots by snapping UV to a grid
	vec2 pixelated_uv = floor(SCREEN_UV * f_max_dots * ratio) / (f_max_dots * ratio);
	// Divides the UV into a grid (subtracts 0.5 to center the dots) and applies dot_size divisor
	float dots = length(fract(SCREEN_UV * f_max_dots * ratio) - vec2(0.5)) / dot_size;

	// Inverts dots value if enabled without using an if statement
	// Since invert is a bool, it will always be converted to 0.0 or 1.0 as a float
	dots = mix(dots, 1.0 - dots, float(invert));

	// Gets the brightness of the color of the current pixelated UV
	// It might be useful to apply a grayscale conversion formula here if your image doesn't work will with the shader
	float brightness = rgb2hsv(texture(SCREEN_TEXTURE, pixelated_uv).rgb).z;
	// Applies brightness modifier to the dots
	dots += brightness * brightness_mult;
	// Makes dots sharper but still retains anti-aliasing
	dots = pow(dots, 5.0);
	// Clamps the dots value to blend with the primary / secondary colors properly
	dots = clamp(dots, 0.0, 1.0);

	// Mixes between the dot and background colors, depending on how dark the dot should be at the current pixel
	vec4 dots_color = mix(primary_color, secondary_color, dots);
	// Applies the original transparency
	dots_color.a *= texture(SCREEN_TEXTURE, SCREEN_UV).a;
	// Sets the output color to one calculated
	COLOR = dots_color;
}
