Film Grain Shader
Full code for the film grain shader tutorial that I wrote. The details of how to implement this shader are discussed in the post. If you simply need the code, its yours & no need for any credit!
Shader code
shader_type canvas_item;
// Uniforms
uniform sampler2D screen_texture : hint_screen_texture;
uniform float grain_amount : hint_range(0.0, 1.0) = 0.05; // Adjust the amount of grain
uniform float grain_size : hint_range(0.1, 10.0) = 1.0; // Adjust the size of the grain
void fragment() {
// Sample the original screen texture
vec4 original_color = texture(screen_texture, SCREEN_UV);
// Generate random noise
float noise = (fract(sin(dot(UV, vec2(12.9898, 78.233))) * 43758.5453) - 0.5) * 2.0;
// Add noise to the original color
original_color.rgb += noise * grain_amount * grain_size;
// Clamp the final color to make sure it stays in the valid range
COLOR = clamp(original_color, 0.0, 1.0);
}
Hi there! I was checking your shader today (which I found thanks to @passivestar) and it worked out of the box.
Thanks for the contribution!
As the image I am working is very static (a 2D scene of a city), I decided to add a time changing element to the grains, by changing one line to:
float noise = (fract(sin(dot(UV, vec2(12.9898, 78.233))) * round(TIME*20.0) *8.5453) – 0.5) *1.5;
I imagine the possibilities of further customization are infinite…
Cheers!
