Simple Laser Shader (SLS)

A simple shader that can be further refined. It is needed for spy games, for decoration.
The shader has no lighting, add a light bulb next to it!

For the particularly ignorant:

1. Create a mesh instance (I recommend a cylinder)

2. Turn it so that it lies like a pipe

3. Create a shader material and paste the code

For the stupid:

1. Copy the shader below!

2. Paste it into the shader editor without touching anything!

If the laser is not glowing, the problem is not with the shader, but with the fact that you did not add a lamp.

Shader code

shader_type spatial;
render_mode unshaded, blend_add;

group_uniforms laser;
uniform vec4 core_color : source_color = vec4(1.0, 0.0, 0.0, 1.0);
uniform vec4 glow_color : source_color = vec4(1.0, 0.5, 0.5, 0.5);
uniform float laser_width : hint_range(0.01, 1.0) = 0.2;
uniform float core_intensity : hint_range(0.1, 5.0) = 1.0;
uniform float core_length : hint_range(0.0, 1.0) = 1.0;
uniform float glow_fade : hint_range(0.1, 30.0) = 0.1;
uniform float glow_shape : hint_range(0.1, 5.0) = 1.0;
uniform float pulse_speed : hint_range(0.0, 10.0) = 2.0;
uniform float pulse_strength : hint_range(0.0, 1.0) = 0.3;
uniform float pulse_dir_x : hint_range(-1.0, 1.0) = 0.0;
uniform float pulse_dir_y : hint_range(-1.0, 1.0) = 0.0;
uniform float pulse_dir_z : hint_range(-1.0, 1.0) = 1.0;
uniform float min_alpha : hint_range(0.0, 1.0) = 0.1;

group_uniforms noise;
uniform float noise_scale : hint_range(0.0, 20.0) = 5.0;
uniform float noise_speed : hint_range(0.0, 5.0) = 1.0;
uniform float noise_strength : hint_range(0.0, 1.0) = 0.1;
uniform float length_noise_scale : hint_range(0.0, 20.0) = 2.0;
uniform float length_noise_speed : hint_range(0.0, 5.0) = 0.5;
uniform float length_noise_strength : hint_range(0.0, 1.0) = 0.05;

group_uniforms oscillation;
uniform float osc_amplitude : hint_range(0.0, 0.5) = 0.05;
uniform float osc_frequency : hint_range(0.0, 20.0) = 5.0;
uniform float osc_speed : hint_range(0.0, 10.0) = 1.0;

float random(vec3 p) {
    return fract(sin(dot(p, vec3(12.9898, 78.233, 45.164))) * 43758.5453);
}

float noise(vec3 p) {
    vec3 i = floor(p);
    vec3 f = fract(p);
    vec3 u = f * f * (3.0 - 2.0 * f);
    return mix(mix(mix(random(i + vec3(0.0, 0.0, 0.0)), random(i + vec3(1.0, 0.0, 0.0)), u.x),
                   mix(random(i + vec3(0.0, 1.0, 0.0)), random(i + vec3(1.0, 1.0, 0.0)), u.x), u.y),
               mix(mix(random(i + vec3(0.0, 0.0, 1.0)), random(i + vec3(1.0, 0.0, 1.0)), u.x),
                   mix(random(i + vec3(0.0, 1.0, 1.0)), random(i + vec3(1.0, 1.0, 1.0)), u.x), u.y), u.z);
}

void vertex() {
    vec3 osc_pos = VERTEX * osc_frequency + vec3(TIME * osc_speed);
    float osc = noise(osc_pos) * osc_amplitude;
    VERTEX += NORMAL * osc;
}

void fragment() {
    vec2 uv = UV;
    vec3 world_pos = (MODEL_MATRIX * vec4(VERTEX, 1.0)).xyz;
    float dist_from_center = length(uv - vec2(0.5, 0.5));
    float length_factor = smoothstep(core_length, core_length - 0.1, abs(VERTEX.z / 5.0));
    float core = smoothstep(laser_width, 0.0, dist_from_center) * length_factor;
    vec3 core_result = core_color.rgb * core * core_intensity;
    float glow = pow(smoothstep(glow_fade, 0.0, dist_from_center), glow_shape) * (1.0 - core);
    vec3 glow_result = glow_color.rgb * glow;
    vec3 pulse_dir = normalize(vec3(pulse_dir_x, pulse_dir_y, pulse_dir_z));
    float pulse_pos = dot(world_pos, pulse_dir);
    float pulse = sin(pulse_pos + TIME * pulse_speed) * pulse_strength + 1.0;
    core_result *= pulse;
    glow_result *= pulse;
    vec3 noise_pos = world_pos * noise_scale + vec3(0.0, 0.0, TIME * noise_speed);
    float noise_value = noise(noise_pos) * noise_strength;
    core_result += noise_value;
    glow_result += noise_value;
    vec3 length_noise_pos = world_pos * length_noise_scale + vec3(0.0, 0.0, TIME * length_noise_speed);
    float length_noise_value = noise(length_noise_pos) * length_noise_strength;
    core_result += length_noise_value;
    glow_result += length_noise_value;
    vec3 final_color = core_result + glow_result * glow_color.a;
    final_color = clamp(final_color, 0.0, 1.0);
    ALBEDO = final_color;
    ALPHA = max(glow + core, min_alpha);
}

Live Preview
