Transparent Ripples

Mostly derived from combining Nevoski’s Ripple shader and Erich_L’s Circular Waves 2D.

I wanted to create a transparent circular ripple pattern that both warped what was in its background and also fully dissapated at the edges of the shaded object. Great for single rainsdrop effects and other “wet” effects.

Like Nevoski’s instructions: attach the shader to a ColorRect and verything behind the ColorRect will be affected by the shader.

Shader code

// Attach to a ColorRect in front of texture/background

shader_type canvas_item;

// Handles the concentric ripples
uniform float frequency: hint_range(0, 15, 0.01) = 4.0;
uniform float amplitude: hint_range(0, 3, 0.1) = 2.0;
uniform float ripple_rate : hint_range(0, 20.0, 1) = 5;

// Handles the waves themselves
uniform float wave_amplitude: hint_range(0.001, 0.1, 0.001) = 0.05;
uniform float wave_frequency: hint_range(0, 15, 0.01) = 4.0;

uniform sampler2D noise;

uniform sampler2D SCREEN_TEXTURE: hint_screen_texture, filter_linear_mipmap;

vec2 wave(vec2 uv, float time) {
    return vec2(
        uv.x + sin(uv.y * wave_frequency + time) * wave_amplitude,
        uv.y + sin(uv.x * wave_frequency + time) * wave_amplitude
    );
}

void fragment() {
	vec2 center_position = -1.0 + 2.0 * UV / (1.0 / TEXTURE_PIXEL_SIZE);
	float center_distance = length(center_position);

	float ripple = sin(center_distance * -frequency * PI + ripple_rate * TIME) * amplitude / (center_distance + 1.0);

	vec2 uv = FRAGCOORD.xy / (1.0 / SCREEN_PIXEL_SIZE).xy + (center_position/center_distance) * ripple * wave_amplitude;
    vec2 background_wave = wave(uv, TIME);
	vec4 background_texture = texture(SCREEN_TEXTURE,background_wave) * sqrt(amplitude);

	float alpha_scalar = (1.0 - min(center_distance, 1.0)) * background_texture.x * 2.5;

	background_texture.a *= 1.0 * alpha_scalar * (ripple + background_texture.x * background_texture.y);
	background_texture.a = max(background_texture.a - (background_texture.y * 0.45), 0.0);

	COLOR = vec4(background_texture.xyz, background_texture.a);

}
