Vaporwave grid tweaks

Origin code from:

https://www.shadertoy.com/view/Wt33Wf

I just add some uniform var to manipulate the grid easier.

Shader code
shader_type canvas_item;

uniform float brightness : hint_range(0.001, 2.0) = 1.0;
uniform float anchor : hint_range(-1.0,0.0) = -0.5;
//The point where all the lines come from.
uniform float speed_scale = 1.0;
uniform float fov : hint_range(0.001, 1.0) = 0.2;
uniform float line_count = 1.0;
uniform vec4 background_color : hint_color = vec4(0.0, 0.1, 0.2, 1.0);
uniform vec4 grid_color : hint_color = vec4(1.0, 0.5, 1.0, 1.0);

float grid(vec2 uv, float batt) {
    vec2 size = vec2(uv.y, uv.y * uv.y * 0.2) * 0.01* (batt + 0.05);
    uv += vec2(0.0, TIME * speed_scale);
    uv = abs(fract(uv) - 0.5);
 	vec2 lines = smoothstep(size, vec2(0.0), uv);
 	lines += smoothstep(size * 5.0, vec2(0.0), uv) * 0.4 * batt;
    return lines.x + lines.y;
}
void fragment() {
	vec2 uv = UV;
	vec4 col = background_color;
    uv.y = 3.0 / (abs(uv.y + fov) + 0.05);
	uv.x += anchor;
    uv.x *= uv.y * line_count;
    float gridVal = grid(uv, brightness);
    col = mix(background_color, grid_color, gridVal);
	COLOR = col;
}
Tags
grid, vaporwave
This shader is a port from an existing Shadertoy project. Shadertoy shaders are by default protected under a Creative Commons Attribution-NonCommercial-ShareAlike 3.0 Unported (CC BY-NC-SA 3.0) license unless anything else has been stated by the author. For more info, see our License terms.
