Wall of Glyphs

This was meant as a challenge to myself to mimic the wall in this tweet: https://twitter.com/Dexerto/status/1708093014030029030.



You should be able to add your own set of symbols, I have provided the one in the screenshot. the noise is just for random information, you should set it and increase the frequency a little bit.



Shader code
shader_type canvas_item;


uniform sampler2D glyphs;
uniform sampler2D noise;
uniform int glyph_w = 1; //The number of horizontal cells on the glyph image.
uniform int glyph_h = 1; //The number of verticle cells on the glyph image.
uniform float cells_w = 10; //number of horizonatal cells on the shader
uniform float cells_h = 10; //shader verticle cells.
uniform float change_sec = 5; //frequency of changes.
//each change: choose a random glyph and a random color, change. must be offset so they dont all change at once.

//from the book of shaders.com
float random (vec2 st) {
    return fract(sin(dot(st.xy,
                         vec2(12.9898,78.233)))*
        43758.5453123);
}

vec3 hsv2rgb(vec3 c)
{
    vec4 K = vec4(1.0, 2.0 / 3.0, 1.0 / 3.0, 3.0);
    vec3 p = abs(fract(c.xxx + K.xyz) * 6.0 - K.www);
    return c.z * mix(K.xxx, clamp(p - K.xxx, 0.0, 1.0), c.y);
}

void fragment() {
	float x = floor(UV.x * cells_w);
	float y = floor(UV.y * cells_h);
	vec2 cell_dim = vec2(1.0 / cells_w, 1.0 / cells_h );
	vec2 localUV = mod(UV, cell_dim) * vec2( cells_w, cells_h);
	COLOR.rg = localUV;
	COLOR.b = 0.0;
	COLOR.a = 1.0;
	vec2 noise_val = texture(noise, vec2(x,y)  * cell_dim ).xy;
	float glyphx = floor( mod(random(vec2(x * x * y + y + floor(TIME * change_sec + noise_val * change_sec  ))) * float(glyph_w),float(glyph_w)) );
	float glyphy = floor( mod(random(vec2(y * y * x + x + floor(TIME * change_sec + noise_val * change_sec  ))) * float(glyph_h),float(glyph_h)) );
	vec2 glyphUV = vec2( glyphx / float(glyph_w), glyphy / float(glyph_h) ) + localUV * vec2((float(cells_w) / cells_w) / float(glyph_w),(float(cells_h) / cells_h) / float(glyph_h)) ;
	vec4 color = texture(glyphs,glyphUV);
	COLOR = color;
	vec3 hue = vec3( random(vec2(x * y + x + y + floor(TIME * change_sec + noise_val * change_sec  ))), 1.0, 1.0);
	hue = hsv2rgb(hue);
	COLOR.rgb = hue;
	//COLOR.rg = glyphUV;
	//COLOR.b = 0.0;
	//COLOR.a = 1.0;
}
The shader code and all code snippets in this post are under CC0 license and can be used freely without the author's permission. Images and videos, and assets depicted in those, do not fall under this license. For more info, see our License terms.
