Circular cut mask

It’s a circular cut mask. Use it on ColorRect or TextureRect. Change progress shader parameter in a script to cut-in and cut-out (maybe even with Tweens because they have different animation modes).

The shader uses circumradius to figure out how far the mask should go. But you can use your own radius, just comment the #define USE_CIRCUMRADIUS line in the shader.

It looks ugly in the editor because it uses screen size to determine its own size. It will look great when you run the game.

Shader code

shader_type canvas_item;

// Comment this if you want to use custom radius
#define USE_CIRCUMRADIUS

/** Transition of the mask effect. */
uniform float progress: hint_range(0.0, 1.0) = 0.5;
/** Center of the circle in normalized UV coordinates. */
uniform vec2 center = vec2(0.5);

#ifndef USE_CIRCUMRADIUS
uniform float radius = 0.5;
#endif

void fragment() {
	float aspect_ratio = SCREEN_PIXEL_SIZE.y / SCREEN_PIXEL_SIZE.x;

	// Scale coords to non-square screens.
	vec2 ar_uv = vec2(aspect_ratio * UV.x, UV.y);
	vec2 ar_center = vec2(aspect_ratio * center.x, center.y);

	vec2 mask = ar_uv - ar_center;

	#ifdef USE_CIRCUMRADIUS
	float d1 = distance(ar_center, vec2(0.0, 0.0));
	float d2 = distance(ar_center, vec2(0.0, 1.0));
	float d3 = distance(ar_center, vec2(aspect_ratio * 1.0, 0.0));
	float d4 = distance(ar_center, vec2(aspect_ratio * 1.0, 1.0));
	float radius = max(max(d1, d2), max(d3, d4));
	#endif

	COLOR.a = step((1.0 - progress) * radius, length(mask));
}
