Simple Hue Shift

This shader shifts the hue value of each pixel by converting its color to HSV color space and incrementing the H value by the desired amount. Every color will be shifted by the same amount, so this shader works best for monochrome textures.

Shader code

shader_type canvas_item;

uniform float shift_amount: hint_range(0.0, 360.0, 1.0) = 0.0;

// Convert RGB color to HSV color space
// Input: vec3 with components in range [0, 1]
// Output: vec3 with h in [0, 360], s and v in [0, 1]
vec3 rgb2hsv(vec3 rgb) {
	float r = rgb.r;
	float g = rgb.g;
	float b = rgb.b;

	float max_val = max(r, max(g, b));
	float min_val = min(r, min(g, b));
	float delta = max_val - min_val;

	float h = 0.0;
	float s = 0.0;
	float v = max_val;

	if (delta > 0.0001) {
		s = delta / max_val;

		if (abs(r - max_val) < 0.0001)      h = (g - b) / delta;
		else if (abs(g - max_val) < 0.0001) h = 2.0 + (b - r) / delta;
		else                                h = 4.0 + (r - g) / delta;

		h *= 60.0;
		if (h < 0.0) h += 360.0;
	}

	return vec3(h, s, v);
}

// Convert HSV color to RGB color space
// Input: vec3 with h in [0, 360], s and v in [0, 1]
// Output: vec3 with components in range [0, 1]
vec3 hsv2rgb(vec3 hsv) {
	float h = hsv.x;
	float s = hsv.y;
	float v = hsv.z;

	float c = v * s;
	float x = c * (1.0 - abs(mod(h / 60.0, 2.0) - 1.0));
	float m = v - c;

	vec3 rgb;

	if (h < 60.0)       rgb = vec3(c, x, 0.0);
	else if (h < 120.0) rgb = vec3(x, c, 0.0);
	else if (h < 180.0) rgb = vec3(0.0, c, x);
	else if (h < 240.0) rgb = vec3(0.0, x, c);
	else if (h < 300.0) rgb = vec3(x, 0.0, c);
	else                rgb = vec3(c, 0.0, x);

	rgb += m;
	return rgb;
}

void fragment() {
	vec3 hsv_color = rgb2hsv(COLOR.rgb);
	hsv_color.x = mod(hsv_color.x + shift_amount, 360.0);
	COLOR.rgb = hsv2rgb(hsv_color);
}

Live Preview
